Kubota B6200HST

Last Updated: September 2024

Overview

The Kubota B6200HST is a small utility tractor made from 1983 to 1992. It has a 2WD chassis and a hydrostatic transmission with 2 forward and 2 reverse gears. This tractor is powered by a Kubota D850-LA-1 engine, which is a 3-cylinder diesel engine with 15 horsepower. The engine is liquid-cooled and naturally aspirated, making it reliable for everyday farm tasks.

This compact tractor measures 102 inches long, 44.9 inches wide, and 70.9 inches tall. It weighs 1,190 pounds, which is light compared to many other tractors. The B6200HST has a Category I rear hitch that can lift up to 1,040 pounds, which is about average for its size. It also has three PTO speeds: 540, 825, and 2500 rpm, giving it versatility for different attachments. The tractor features an open operator station and electric starter, making it easy to use and maintain.
Show more...

Key Specifications

Category: Utility

Power Output: 15 hp (11.2 kW)

Transmission: Hydrostatic

Drive Type: 2WD

Operating Weight: 1190 lb (540 kg)

Fuel Type: Diesel

Kubota B6200HST vs. Similar Tractors

Power Output

The Power Output for the Kubota B6200HST is Poor. It is greater than 3% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 4.7K+ tractors in our database)

Operating Weight

The Operating Weight for the Kubota B6200HST is Poor. It is greater than 1% of similar Utility tractors in our database.

Operating weight distribution of Utility tractors

(across 4.4K+ tractors in our database)

Engine Displacement

The Engine Displacement for the Kubota B6200HST is Poor. It is greater than 3% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
Kubota
Model
D850-LA-1
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Fuel Type
Diesel
Induction Type
Natural aspiration
Cylinders
3
Displacement
52 ci (0.9 L)
Bore
2.83 in (71.9 mm)
Stroke
2.76 in (70.1 mm)
Power Output
15 hp (11.2 kW)

Transmission

Type
Hydrostatic
Forward Gears
2
Reverse Gears
2

Drivetrain

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Manual, ball screw type
Brake Type
Internal Expanding Type
