Kubota B3350HSDCC

Last Updated: June 2024

Overview

The Kubota B3350HSDCC is a compact utility tractor equipped with a Kubota V1505-T-E4-D26-QC diesel engine. It showcases a liquid-cooling system and delivers a gross horsepower of 33 and a net of 27 hp at 2500 RPM. The tractor's open-center hydraulic system, together with its three-point hitch, which has a lift capacity of 1675.6 lbs, provides enough versatility for various attachments. A wet disk brake system ensures reliable stopping power. This tractor also features a hydrostatic transmission with three forward and reverse gears, allowing for a mix of speed and control during operation. Its operating weight is around 2447.2 lbs, and it possesses a robust stature with an overall height of 84 inches and length of 114.2 inches. The specific tire dimensions remain unknown, but it sports standard agricultural front and rear tires, likely in line with its compact utility category.

Key Specifications

Power Output: Gross: 33, Net: 27 (assuming "Horsepower - Gross" is equivalent to "Power Output (hp)")

Transmission: Main-hydrostatic transmission

Operating Weight: 2447.2

Fuel Type: Diesel (Indirect Injection implies diesel)

Lift Capacity: 1675.6 lbs

Image Gallery

Kubota B3350HSDCC Tractor

Technical Specifications

Engine

Manufacturer: Kubota
Model: V1505-T-E4-D26-QC
Cooling Type: Liquid (Pressurized radiator)
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel (Indirect Injection implies diesel)
Induction Type: -
Cylinders: 4
Displacement (ci): 91.5
Bore (in): 3.1
Stroke (in): 3.1
Rated RPM: 2500
Power Output (hp): Gross: 33, Net: 27 (assuming "Horsepower - Gross" is equivalent to "Power Output (hp)")

Transmission

Type: Main-hydrostatic transmission
Forward Gears: 3
Reverse Gears: 3
Total Gears: -

Dimensions

Length (in): 114.2
Width (in): 1365 (unsure conversion, given as feet in data, likely error)
Height (in): 84 (conversion from 7.1 feet)
Operating Weight (lb): 2447.2

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): Mid: 2500
PTO Speed 2 (rpm): Rear: 540
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: -
Drive Type: -
Steering Type: -
Coolant Capacity (qts): 4.8 (converted from 1.2 gallons)
Front Tire Diameter (in): -
Front Tire Width (in): Unknown (The size 7 - 12 likely indicates a 12-inch rim, but since the tires are not standard automotive sizes, the actual figures are unassumable)
Rear Tire Diameter (in): -
Rear Tire Width (in): Unknown (The size 12.4-16 likely indicates a 16-inch rim, but since the tires are not standard automotive sizes, the actual figures are unassumable)
Front/Rear Rim Diameter (in): Front: Unknown, Rear: 16 (assumed based on the tire size provided)
Tire Type: -
Manufacture - End Year: -
Hitch Type: Three-Point Hitch
Hitch Category: Category 1
Hitch Position: -
Hitch Capacity (lb): 1675.6 lbs
Operator Station Type: -
Starter Type: -
Brake Type: Wet disk type
Hydraulic System Type: Open center
