Kubota B3350HSDC

Last Updated: June 2024

Overview

The Kubota B3350HSDC is a utility tractor that offers a significant power output of 33 hp from its Kubota-manufactured 4-cylinder turbocharged diesel engine. It features a hydrostatic transmission with 3 forward and 3 reverse gears, housed in a 4x4 chassis configuration. The tractor is designed with user comfort in mind, given the likely presence of a cab (denoted by the 'HSDC' in the model name). For efficient operation, it comes with a pressurized radiator cooling system and a hydraulic system functioning with an open center type. The tractor is equipped with both mid and rear PTOs, offering 2500 rpm and 540 rpm respectively, which are adaptable for a variety of attachments and implements. Safety and maneuverability are addressed with wet disk brakes and a standard differential lock, enhancing traction on uneven terrains. Its size and power make it suitable for various tasks around a smaller farm or acreage.
Show more...

Key Specifications

Category: Utility

Power Output: 33

Transmission: Hydrostatic

Drive Type: 4WD

Operating Weight: 2447.2

Fuel Type: Diesel

Kubota B3350HSDC vs. Similar Tractors

Power Output
Below Average
Greater than 29% of similar tractors.
Hitch Capacity
Average
Greater than 30% of similar tractors.
Operating Weight
Below Average
Greater than 19% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V1505-T-E4-D26-Q
Cooling Type
Pressurized radiator
Cylinder Orientation
-
Valve Configuration
Indirect Injection (Assumed to be OHV but not explicitly stated)
Fuel Type
Diesel
Induction Type
Turbocharged (Assumed due to the '-T-' in the engine model indicating turbo)
Cylinders
4
Displacement (ci)
91.5
Bore (in)
3.1
Stroke (in)
3.1
Rated RPM
2500
Power Output (hp)
33

Transmission

Type
Hydrostatic
Forward Gears
3
Reverse Gears
3
Total Gears
-

Dimensions

Length (in)
114.2
Width (in)
Unknown (Data appears incorrect: '1365 ft')
Height (in)
85.2 (Converted from 7.1 ft)
Operating Weight (lb)
2447.2

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
2500
PTO Speed 2 (rpm)
540
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4
Drive Type
4WD
Steering Type
Power (Assumed based on the model and category)
Coolant Capacity (qts)
4.8 (Converted from 1.2 gal)
Front Tire Diameter (in)
Unknown (Size given in tire type, not diameter)
Front Tire Width (in)
Unknown (Size given in tire type, not width)
Rear Tire Diameter (in)
Unknown (Size given in tire type, not diameter)
Rear Tire Width (in)
Unknown (Size given in tire type, not width)
Front/Rear Rim Diameter (in)
-
Tire Type
Front - Bar, Rear - Agriculture
Manufacture - End Year
-
Hitch Type
Three-Point Hitch
Hitch Category
Category 1
Hitch Position
Rear
Hitch Capacity (lb)
1675.6 (lbs)
Operator Station Type
Cab (Assumed based on the model designation 'HSDC')
Starter Type
Electric (Assumed due to commonality in modern tractors)
Brake Type
Wet Disk
Hydraulic System Type
Open Center
