Kubota B3350

Last Updated: June 2024

Overview

The Kubota B3350 compact utility tractor is a durable and versatile machine designed for a variety of tasks. Manufactured since 2013, it incorporates a Kubota V1505-T four-cylinder turbocharged diesel engine and a hydrostatic transmission with infinite (3-range) gears for adaptive speed control in forward and reverse. This model is equipped with hydrostatic power steering and wet disc brakes, ensuring responsive handling and safe stopping power. The B3350 is available with either a traditional open operator station with ROPS or a cab option for increased comfort. Known for its reliability and power, the engine delivers 33 hp with a rated RPM of 2500, complemented by a Category I hitch system with a lift capacity of 2139 lbs for efficient towing and lifting capabilities.

Key Specifications

Category: Utility

Power Output: 33

Transmission: Hydrostatic

Drive Type: MFWD (Mechanical Front Wheel Drive)

Operating Weight: 1896 (ROPS), 2447 (cab)

Fuel Type: Diesel

Image Gallery

Kubota B3350 Tractor

Kubota B3350 vs. Similar Tractors

Power Output

Below Average

Greater than 29% of similar tractors.

Hitch Capacity

Average

Greater than 37% of similar tractors.

Operating Weight

Below Average

Greater than 15% of similar tractors.

Technical Specifications

Engine

Manufacturer: Kubota
Model: V1505-T
Cooling Type: Liquid-cooled
Cylinder Orientation: Inline
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Turbocharged
Cylinders: 4
Displacement (ci): 91.5
Bore (in): 3.1
Stroke (in): 3.1
Rated RPM: 2500
Power Output (hp): 33

Transmission

Type: Hydrostatic
Forward Gears: Infinite (3-range)
Reverse Gears: Infinite (3-range)
Total Gears: -

Dimensions

Length (in): 101.2
Width (in): 53.7
Height (in): 88.4 (ROPS), 84.6 (cab)
Operating Weight (lb): 1896 (ROPS), 2447 (cab)

Power Take-Off (PTO)

PTO Type: Independent with hydraulic clutch
PTO Speed 1 (rpm): 540
PTO Speed 2 (rpm): 2500 (Mid PTO)
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: MFWD (Mechanical Front Wheel Drive)
Steering Type: Hydrostatic power
Coolant Capacity (qts): 4.5
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Ag: Front: 7-12, Rear: 12.4-16 | Lawn/turf front: 24x8.50-14, Lawn/turf rear: 13.6-16 | Industrial front: 23x8.50-14, Industrial rear: 12.4-16
Manufacture - End Year: -
Hitch Type: Category I
Hitch Category: Category 3
Hitch Position: Rear
Hitch Capacity (lb): 2139 lbs
Operator Station Type: Open operator station with two-post ROPS or Cab (option)
Starter Type: Electric
Brake Type: Wet disc
Hydraulic System Type: Open center
