Kubota B2910HSD

Last Updated: June 2024

Overview

The Kubota B2910HSD is a compact utility tractor that provides versatility for a variety of tasks around the farm or homestead. It is equipped with a four-wheel-drive chassis, ensuring traction in various conditions, and utilizes a Kubota V1505 diesel engine producing 30 horsepower with a displacement of 91.5 cubic inches. The engine operates at 2600 RPM and is capable of delivering a PTO power of 22 horsepower. Hydrostatic transmission with three ranges allows for smooth and effortless shifting of speed and direction. With an operating weight of 1763 pounds, a rear Category 1 three-point hitch with a lift capacity of over 1300 pounds, and a hydraulic flow of 9.6 gallons per minute, this model can handle various implements and tasks with ease. The tractor's compact dimensions make it suitable for tight spaces, although exact length and tire dimensions have not been specified.
Show more...

Key Specifications

Category: Utility

Power Output: 30

Transmission: Hydrostatic

Drive Type: 4WD (assumed based on Kubota’s typical compact utility tractor offerings)

Operating Weight: 1763

Fuel Type: Diesel (inferred from Engine - Aspiration and typical fuel type for Kubota engines with model codes like V1505)

Image Gallery

Kubota B2910HSD Tractor Kubota B2910HSD Tractor Kubota B2910HSD Tractor Kubota B2910HSD Tractor Kubota B2910HSD Tractor Kubota B2910HSD Tractor Kubota B2910HSD Tractor Kubota B2910HSD Tractor

Kubota B2910HSD vs. Similar Tractors

Power Output
Below Average
Greater than 25% of similar tractors.
Hitch Capacity
Below Average
Greater than 24% of similar tractors.
Operating Weight
Below Average
Greater than 14% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V1505
Cooling Type
Liquid
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel (inferred from Engine - Aspiration and typical fuel type for Kubota engines with model codes like V1505)
Induction Type
E-TVCS liquid cooled (assumed to be normally aspirated with electronic TVCS technology)
Cylinders
4
Displacement (ci)
91.5
Bore (in)
-
Stroke (in)
-
Rated RPM
2600
Power Output (hp)
30

Transmission

Type
Hydrostatic
Forward Gears
Unknown (specific number of hydrostatic control positions not provided, but "HST 3 range" implies three primary speed ranges)
Reverse Gears
Unknown (specific number of hydrostatic control positions not provided, but "HST 3 range" implies three primary speed ranges)
Total Gears
Unknown (HST implies a continuum of gear ratios rather than discrete gears)

Dimensions

Length (in)
Incorrect data provided (8.3 inches is not plausible for overall length; likely a misunderstanding or typo)
Width (in)
54 (converted from 4.5 feet)
Height (in)
-
Operating Weight (lb)
1763

Power Take-Off (PTO)

PTO Type
Unknown (likely transmission or independent based on the tractor's category and horsepower)
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 (assumed from tire size information and typical configuration for Kubota compact utility tractors)
Drive Type
4WD (assumed based on Kubota’s typical compact utility tractor offerings)
Steering Type
-
Coolant Capacity (qts)
4.8 (converted from 1.2 gallons)
Front Tire Diameter (in)
Unknown (size given as model number and not dimensions)
Front Tire Width (in)
Unknown (size given as model number and not dimensions)
Rear Tire Diameter (in)
Unknown (size given as model number and not dimensions)
Rear Tire Width (in)
Unknown (size given as model number and not dimensions)
Front/Rear Rim Diameter (in)
-
Tire Type
Unknown (typically agricultural for compact utility tractors, but not specifically provided)
Manufacture - End Year
-
Hitch Type
Three-Point Hitch
Hitch Category
Category 1
Hitch Position
Rear
Hitch Capacity (lb)
1300.8
Operator Station Type
-
Starter Type
Unknown (likely electric based on standard modern practices)
Brake Type
-
Hydraulic System Type
Unknown (9.6 gal/min flow suggests open center but not confirmed)
