Kubota B2401

Last Updated: June 2024

Overview

The Kubota B2401 is a compact utility tractor from the reputable manufacturer Kubota. It features a 4x4 MFWD 4WD chassis, emphasizing its capability for operating in a variety of terrain and conditions. Its power steering provides better maneuverability and ease of control. Equipped with a 9-speed gear transmission, it allows for a good range of speed options during operation. The heart of this machine is its reliable Kubota D1105, a 3-cylinder, 68.5 cubic inch displacement, liquid-cooled diesel engine that generates 21.9 horsepower at 2600 RPM, using a dry-type air cleaner. The tractor’s 1521-pound operating weight is well balanced with its wheelbase of 61.4 inches, ensuring stability during use. Its physical dimensions also enable it to navigate through tighter spaces than larger agricultural tractors would be able to handle. Overall, the B2401 is built for versatility and durability, which Kubota users have come to expect from the B-01 Series tractors.
Show more...

Key Specifications

Category: Utility

Power Output: 21.9

Transmission: Gear

Drive Type: 4WD

Operating Weight: 1521

Fuel Type: Diesel

Kubota B2401 vs. Similar Tractors

Power Output
Below Average
Greater than 12% of similar tractors.
Operating Weight
Below Average
Greater than 12% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
D1105
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
68.5
Bore (in)
3.07
Stroke (in)
3.09
Rated RPM
2600
Power Output (hp)
21.9

Transmission

Type
Gear
Forward Gears
9
Reverse Gears
3
Total Gears
-

Dimensions

Length (in)
93.9
Width (in)
44.3
Height (in)
83.9
Operating Weight (lb)
1521

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
4
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
Category I Three-Point Hitch
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open Center
