Kioti LK3054XS

Last Updated: June 2024

Overview

The Kioti LK3054XS is a Compact Utility tractor that provides a balance of functionality and power for various tasks. With a robust four-wheel drive (4x4 MFWD 4WD) system and mechanical shuttle transmission that offers 8 forward and reverse gears, it delivers smooth handling and control in a variety of conditions. Its solid construction includes a wheelbase of 64.6 inches for stability and a weight of 2974 lbs for substantial towing and lifting capability. At the heart of the tractor is a Daedong TD14008B-1 diesel engine, which is liquid-cooled and provides 30.5 horsepower. This tractor offers flexibility for different jobs thanks to its various standard and optional tire setups, including options for agricultural, turf, and industrial applications. The tractor dimensions ensure a compact profile with a length of 111.4 inches, width of 51.7 inches, and height of 80.3 inches with the ROPS. Although specifics about the hydraulic system are not detailed, its type is open center, which complements its capability set. This model's ratings and features establish it as a versatile and reliable machine for landscaping, farming, and other utility tasks.

Key Specifications

Category: Utility

Power Output: 30.5

Transmission: Mechanical shuttle

Drive Type: 4WD

Operating Weight: 2974

Fuel Type: Diesel

Image Gallery

Kioti LK3054XS Tractor

Kioti LK3054XS vs. Similar Tractors

Power Output

Below Average

Greater than 25% of similar tractors.

Operating Weight

Below Average

Greater than 24% of similar tractors.

Technical Specifications

Engine

Manufacturer: Daedong
Model: TD14008B-1
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: -
Cylinders: 3
Displacement (ci): 85.1
Bore (in): -
Stroke (in): -
Rated RPM: 2700
Power Output (hp): 30.5

Transmission

Type: Mechanical shuttle
Forward Gears: 8
Reverse Gears: 8
Total Gears: -

Dimensions

Length (in): 111.4
Width (in): 51.7
Height (in): 80.3 (with ROPS)
Operating Weight (lb): 2974

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: -
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): 24 (assuming the 11.2-24 tire specification follows standard notation where the diameter is the last number)
Rear Tire Width (in): 11.2
Front/Rear Rim Diameter (in): -
Tire Type: Agricultural, Turf, Industrial (Standard, Optional, and Industrial)
Manufacture - End Year: -
Hitch Type: Category I
Hitch Category: Category 3 (this seems to contradict the data, as Compact Utility tractors typically come with Cat 1 hitches, making it unlikely to be Cat 3)
Hitch Position: Rear
Hitch Capacity (lb): -
Operator Station Type: Unknown (ROPS indicates a roll bar, but not if it's part of a cab or open station)
Starter Type: Electric
Brake Type: -
Hydraulic System Type: Open Center
