Kioti LK3052

Last Updated: June 2024

Overview

The Kioti LK3052 is a utility tractor outfitted with essential features for a variety of tasks. It is powered by a 30.5 horsepower Daedong TD1400 diesel engine with a displacement of 85.1 cubic inches. The liquid-cooled engine has 3 cylinders and operates at a rated speed of 2600 RPM. Its electric starter simplifies the ignition process, and pre-heating is achieved with glow plugs. The transmission is a synchronized shuttle type, providing 8 forward and reverse gears, suited for tasks requiring varying speeds. With power steering, operating this tractor is less strenuous on the operator during long working hours. Constructed with a dry disc clutch, it ensures durability and reliability in power transmission from the engine to the drivetrain. The total length, width, and height of the tractor are 111.4 inches, 51.7 inches, and 80.3 inches, respectively, and it has a wheelbase of 64.6 inches, contributing to its stability. The weight of the tractor is 2866 pounds, giving it a solid presence and ensuring traction on varied terrains. The tractor rides on agricultural tires, with sizes 5.50-16 in the front and 11.2-24 at the rear; available lawn/turf tires provide an alternative for different working conditions. It also offers a ground clearance of 10.8 inches, making it well-suited to navigate over uneven terrain.
Show more...

Key Specifications

Category: Utility

Power Output: 30.5

Transmission: Synchronized shuttle

Operating Weight: 2866

Fuel Type: Diesel

Kioti LK3052 vs. Similar Tractors

Power Output
Below Average
Greater than 25% of similar tractors.
Operating Weight
Below Average
Greater than 23% of similar tractors.

Technical Specifications

Engine

Manufacturer
Daedong
Model
TD1400
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
85.1
Bore (in)
3.35
Stroke (in)
3.22
Rated RPM
2600
Power Output (hp)
30.5

Transmission

Type
Synchronized shuttle
Forward Gears
8
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
111.4
Width (in)
51.7
Height (in)
80.3
Operating Weight (lb)
2866

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Rear Type I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open center
