Kioti LK30

Last Updated: June 2024

Overview

The Kioti LK30 is a compact utility tractor engineered to handle a range of tasks on a small farm or homestead. Equipped with a four-wheel-drive chassis, it provides increased traction and power on varied terrain. The hydrostatic power steering facilitates maneuverability during operations. Its 30 horsepower Daedong diesel engine with a liquid-cooled 3-cylinder inline configuration delivers consistent and reliable performance. Operating at a rated 2600 RPM, it achieves greater efficiency with an 8-speed synchronized shuttle transmission, offering equal numbers of forward and reverse gears. The tractor’s utilitarian nature is enhanced by its multiple tire options catering to different ground conditions, from agricultural and turf to industrial applications. A ROPS (Roll-Over Protective Structure) ensures operator safety during use. Although the information on the tractor's hydraulic systems, PTO speed, and hitch capabilities is limited, the existing specifications highlight a versatile and robust machine, suitable for a range of medium-duty farming tasks.
Show more...

Key Specifications

Power Output: 30

Transmission: Synchronized shuttle

Drive Type: 4WD

Operating Weight: 2,897

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Daedong
Model
3A150LWB
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
91.5
Bore (in)
-
Stroke (in)
-
Rated RPM
2600
Power Output (hp)
30

Transmission

Type
Synchronized shuttle
Forward Gears
8
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
111.4
Width (in)
51.4
Height (in)
88.6
Operating Weight (lb)
2,897

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
Unknown (assumed to follow standard sizes for selected type)
Front Tire Width (in)
Unknown (assumed to follow standard sizes for selected type)
Rear Tire Diameter (in)
24 (from rear tire size 11.2-24)
Rear Tire Width (in)
11.2 (from rear tire size 11.2-24)
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural, Lawn/Turf, Industrial (based on tire size options)
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
ROPS
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
