Kioti LB1714

Last Updated: June 2024

Overview

The Kioti LB1714 is a compact utility tractor, ideal for a variety of tasks due to its 4-wheel drive (4x4 MFWD 4WD) chassis. Equipped with manual steering, it features an 8-speed partial synchromesh transmission with a mechanical shuttle, providing ample variability in power and control. The tractor is powered by a Daedong TD 950 diesel engine which delivers 17 horsepower with a displacement of 56.6 cubic inches. This engine is liquid-cooled and operates at a rated 2600 RPM. The LB1714 runs on a variety of tire options, with specified sizes for agricultural and lawn/turf missions, highlighting its versatility. With a weight of 1,900 lbs and a wheelbase of 56 inches, it presents a stable platform for a host of agricultural tasks, all while ensuring comfort with its 75-inch height to exhaust. Ensuring easy starts in cold conditions are the incorporated glow plugs, representing the additional pre-heating feature. This practical and robust tractor is a suitable option for those requiring a dependable machine for diverse farming operations.
Show more...

Key Specifications

Category: Utility

Power Output: 17

Transmission: Partial synchromesh

Drive Type: MFWD (Mechanical Front Wheel Drive) or 4WD

Operating Weight: 1,900

Fuel Type: Diesel

Kioti LB1714 vs. Similar Tractors

Power Output
Poor
Greater than 6% of similar tractors.
Operating Weight
Poor
Greater than 0% of similar tractors.

Technical Specifications

Engine

Manufacturer
Daedong
Model
TD 950
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated (assumed due to lack of any detail indicating forced induction)
Cylinders
3
Displacement (ci)
56.6
Bore (in)
-
Stroke (in)
-
Rated RPM
2600
Power Output (hp)
17

Transmission

Type
Partial synchromesh
Forward Gears
8
Reverse Gears
7
Total Gears
-

Dimensions

Length (in)
98.1
Width (in)
44.1
Height (in)
75 (to exhaust)
Operating Weight (lb)
1,900

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
MFWD (Mechanical Front Wheel Drive) or 4WD
Steering Type
Manual
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag tires (9.5-20 or 12.4-16), Lawn/turf (23x8.50-12 front and 36x13.50-15 rear)
Manufacture - End Year
-
Hitch Type
Category I three-point hitch
Hitch Category
Unknown, assumed to be Category I based on Rear Type I
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
