Kioti DK801

Last Updated: June 2024

Overview

The Kioti DK801 is a utility tractor designed to meet various farming and heavy-duty landscape needs. The tractor features a powerful Perkins 1104C-44T turbocharged diesel engine that delivers 80 horsepower and contains a displacement of 268.5 cubic inches. It operates at an engine rated RPM of 2200 and uses a liquid cooling system. Equipped with a 4-wheel drive MFWD 4WD chassis and power steering, the DK801 offers a high degree of maneuverability and traction. The synchromesh transmission provides 12 forward and reverse gears, suitable for a range of tasks. The open center hydraulic system, equipped with a Category II three-point hitch, demonstrates the tractor's ability to handle various implements easily. Its large operating weight of 7542 pounds, coupled with a wheelbase measuring 84.3 inches, ensures stability during operations. Standard ag tires are sized at 12.4-24 for the front and 18.4-34 for the rear, but exact tire diameters and widths are not specified. The tractor's dimensions provide a substantial footprint, contributing to its capability in diverse conditions.
Show more...

Key Specifications

Category: Utility

Power Output: 80

Transmission: Synchromesh

Drive Type: 4WD

Operating Weight: 7542

Fuel Type: Diesel

Kioti DK801 vs. Similar Tractors

Power Output
Above Average
Greater than 71% of similar tractors.
Operating Weight
Average
Greater than 55% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
1104C-44T
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
268.5
Bore (in)
4.135
Stroke (in)
5
Rated RPM
2200
Power Output (hp)
80

Transmission

Type
Synchromesh
Forward Gears
12
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
168
Width (in)
73
Height (in)
Unknown (Height varies based on whether ROPS or cab is installed)
Operating Weight (lb)
7542

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
19.6
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
-
Hitch Type
Category II three-point hitch
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open center
