Kioti DK50SE

Last Updated: June 2024

Overview

The Kioti DK50SE is a compact utility tractor known for its reliability and versatility. Equipped with a 4-cylinder Daedong diesel engine that provides 49 horsepower and a hydrostatic transmission with an infinite (3-range) selection of forward and reverse gears, it is designed to handle a variety of tasks. The tractor features a modern 4WD chassis, hydrostatic power steering, and a liquid-cooled engine to ensure smooth operation under different working conditions. With operator safety in mind, it has a ROPS height of 95 inches and a cabin option height of 96.7 inches. The wheelbase of 74 inches contributes to its stability, while the ground clearance of 14.7 inches allows for operation in varied terrains. The DK50SE is well-suited for a range of environments given its substantial operating weight of 3902 pounds for the ROPS version and the utility provided by its different tire configurations for agricultural, lawn/turf, and industrial applications.
Show more...

Key Specifications

Category: Utility

Power Output: 49

Transmission: hydrostatic

Drive Type: 4WD

Operating Weight: 3902 (ROPS)

Fuel Type: diesel

Kioti DK50SE vs. Similar Tractors

Power Output
Average
Greater than 47% of similar tractors.
Operating Weight
Average
Greater than 35% of similar tractors.

Technical Specifications

Engine

Manufacturer
Daedong
Model
4B243LWH
Cooling Type
liquid-cooled
Cylinder Orientation
inline
Valve Configuration
-
Fuel Type
diesel
Induction Type
-
Cylinders
4
Displacement (ci)
148
Bore (in)
-
Stroke (in)
-
Rated RPM
2600
Power Output (hp)
49

Transmission

Type
hydrostatic
Forward Gears
infinite (3-range)
Reverse Gears
infinite (3-range)
Total Gears
-

Dimensions

Length (in)
134.2
Width (in)
63.9
Height (in)
95 (ROPS), 96.7 (cab)
Operating Weight (lb)
3902 (ROPS)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
24
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
electric
Brake Type
-
Hydraulic System Type
-
