Kioti CK4210

Last Updated: June 2024

Overview

The Kioti CK4210 is a compact utility tractor designed for a variety of tasks on the farm or homestead. Equipped with a 4-wheel drive chassis and power steering, it offers robust performance and maneuverability. At its heart lies a reliable Daedong three-cylinder diesel engine, model 3B183LWM-E, with a liquid-cooling system, capable of producing 38 horsepower with an engine displacement of 111.6 cubic inches. The tractor offers dual transmission options with a 9-speed gear and a hydrostatic variant providing infinite three-range forward and reverse speeds. The CK4210's dimensions and tire setup suggest that it's built for stability and suitable for diverse terrain, with standard agricultural tires supporting this versatility. The tractor's specific hydraulic, PTO, hitch, and operator station details, as well as additional feature specifications, are not provided.
Show more...

Key Specifications

Category: Utility

Power Output: 38

Transmission: Gear / Hydrostatic (Dual options available)

Drive Type: 4WD

Fuel Type: Diesel

Kioti CK4210 vs. Similar Tractors

Power Output
Average
Greater than 35% of similar tractors.

Technical Specifications

Engine

Manufacturer
Daedong
Model
3B183LWM-E
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated (assumed, as no turbo/supercharger indicated)
Cylinders
3
Displacement (ci)
111.6
Bore (in)
3.43
Stroke (in)
4.03
Rated RPM
2600
Power Output (hp)
38

Transmission

Type
Gear / Hydrostatic (Dual options available)
Forward Gears
9
Reverse Gears
3
Total Gears
-

Dimensions

Length (in)
120.9
Width (in)
55.1
Height (in)
104.3
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
25
Front Tire Width (in)
8.5
Rear Tire Diameter (in)
19.5
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag (Agricultural)
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open center
