Kioti CK30 HST

Last Updated: June 2024

Overview

The Kioti CK30 HST is a utility tractor designed for various agricultural and general purpose tasks. It features a hydrostatic transmission with a 3-range infinite number of forward gears and a standard 4WD (four-wheel drive) chassis for improved traction and maneuverability. The tractor is powered by a 30 horsepower diesel engine, with an engine displacement of 91.5 cubic inches and a power measured at 2600 RPM. A Category 1 three-point hitch system is equipped with the ability to lift up to 1763.7 pounds, making it suitable for a wide range of implements. The operating weight of the vehicle is 3143.8 pounds, ensuring stability when performing heavy-duty tasks. The Kioti CK30 HST is built to handle demanding tasks with ease, though the dimensions may suggest it is also agile enough for smaller spaces.

Key Specifications

Category: Utility

Power Output: 30

Transmission: Hydrostatic

Drive Type: 4WD

Operating Weight: 3143.8

Fuel Type: Diesel

Image Gallery

Kioti CK30 HST Tractor

Kioti CK30 HST vs. Similar Tractors

Power Output

Below Average

Greater than 25% of similar tractors.

Hitch Capacity

Average

Greater than 32% of similar tractors.

Operating Weight

Below Average

Greater than 26% of similar tractors.

Technical Specifications

Engine

Manufacturer: Kioti
Model: 3A150LWH
Cooling Type: -
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: -
Cylinders: 3
Displacement (ci): 91.5
Bore (in): -
Stroke (in): -
Rated RPM: 2600
Power Output (hp): 30

Transmission

Type: Hydrostatic
Forward Gears: 3-range infinite
Reverse Gears: -
Total Gears: -

Dimensions

Length (in): 122.4
Width (in): 55.2
Height (in): 97.2
Operating Weight (lb): 3143.8

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4
Drive Type: 4WD
Steering Type: Power
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Agricultural
Manufacture - End Year: -
Hitch Type: Three-Point Hitch
Hitch Category: Category 1
Hitch Position: Rear
Hitch Capacity (lb): 1763.7
Operator Station Type: -
Starter Type: -
Brake Type: -
Hydraulic System Type: -
