Kioti CK27

Last Updated: June 2024

Overview

The Kioti CK27 is a compact utility tractor engineered for a variety of tasks around the farm or estate. It is equipped with a 28 hp Daedong diesel engine and has a choice of either a synchronized shuttle or hydrostatic transmission, featuring 8 forward and reverse gears. This model comes with a 4WD chassis offering improved traction over various terrains. The CK27’s power steering provides easier maneuverability, and its three-point hitch category I system with a lift capacity of approximately 1763.7 pounds allows for the utilization of various implements. A notable feature is the tractor's ample ground clearance of 13.9 inches and a wheelbase of 66.1 inches, providing stability during operation. The tractor operates at a rated RPM of 2600, with an electric starter system for the engine. Though compact, the tractor's weight ranges from 3117 to 3161 pounds, indicative of its solid build and capability. For those working their land, the Kioti CK27 offers a robust set of features catered to efficient land management and agricultural tasks.
Show more...

Key Specifications

Category: Utility

Power Output: 28

Transmission: synchronized shuttle / hydrostatic

Drive Type: 4WD

Operating Weight: 3117 to 3161

Fuel Type: diesel

Kioti CK27 vs. Similar Tractors

Power Output
Below Average
Greater than 23% of similar tractors.
Hitch Capacity
Average
Greater than 32% of similar tractors.
Operating Weight
Above Average
Greater than 84% of similar tractors.

Technical Specifications

Engine

Manufacturer
Daedong
Model
3A139LWM
Cooling Type
liquid-cooled
Cylinder Orientation
inline
Valve Configuration
-
Fuel Type
diesel
Induction Type
natural
Cylinders
3
Displacement (ci)
85
Bore (in)
3.15
Stroke (in)
3.64
Rated RPM
2600
Power Output (hp)
28

Transmission

Type
synchronized shuttle / hydrostatic
Forward Gears
8
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
122.2
Width (in)
54.6
Height (in)
96.8
Operating Weight (lb)
3117 to 3161

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Three-Point Hitch
Hitch Category
I
Hitch Position
Rear
Hitch Capacity (lb)
1763.7
Operator Station Type
-
Starter Type
electric
Brake Type
-
Hydraulic System Type
-
