Kioti CK20S HST

Last Updated: June 2024

Overview

The Kioti CK20S HST is a utility tractor that exemplifies versatility and functionality. It is designed for various tasks, from property maintenance to farming work. Equipped with a 22 horsepower diesel engine (Model 3C100A), this tractor is capable of delivering sufficient power for its class. The Kioti CK20S HST operates with a hydrostatic transmission featuring infinite forward and reverse gears within two ranges, ensuring precise control and ease of operation. The tractor’s four-wheel drive (4WD) chassis complements the power steering system, making it easy to manage even in tight spaces with a turning radius of 7.6 ft. Its three-point hitch (Category I) with a lift capacity of 1109 lbs enables it to handle a variety of implements efficiently. The tractor has an operating weight of 2138.5 lbs and fits into the landscape with modest dimensions, standing at 86.4 inches tall, with an overall length of 106.3 inches and a width of 44.3 inches. The engine's displacement is listed at 61.5 cubic inches, and it revs up to a rated speed of 2800 RPM, ensuring capable performance across its operational spectrum. The CK20S HST embodies the qualities expected from a compact tractor and serves as a reliable asset for users seeking a machine that balances size with power and maneuverability.
Show more...

Key Specifications

Category: Utility

Power Output: 22

Transmission: Hydrostatic

Drive Type: 4WD

Operating Weight: 2138.5

Fuel Type: Diesel

Kioti CK20S HST vs. Similar Tractors

Power Output
Below Average
Greater than 13% of similar tractors.
Hitch Capacity
Excellent
Greater than 93% of similar tractors.
Operating Weight
Below Average
Greater than 17% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kioti
Model
3C100A
Cooling Type
Liquid
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Natural
Cylinders
3
Displacement (ci)
61.5
Bore (in)
-
Stroke (in)
-
Rated RPM
2800
Power Output (hp)
22

Transmission

Type
Hydrostatic
Forward Gears
Infinite (2 range)
Reverse Gears
Infinite (2 range)
Total Gears
-

Dimensions

Length (in)
106.3
Width (in)
44.3
Height (in)
86.4
Operating Weight (lb)
2138.5

Power Take-Off (PTO)

PTO Type
Transmission
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
12
Front Tire Width (in)
-
Rear Tire Diameter (in)
16
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Three-Point Hitch
Hitch Category
I
Hitch Position
Rear
Hitch Capacity (lb)
1109 lbs at 24 inches behind lift points
Operator Station Type
Open
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
