Kioti CK20

Last Updated: June 2024

Overview

The Kioti CK20 is a compact utility tractor that was manufactured by Daedong from 2003 to 2007, primarily designed for a variety of tasks in a small farm, garden, or estate. It is outfitted with a robust Daedong 3C093, three-cylinder, liquid-cooled diesel engine that provides 21 horsepower at 2800 RPM. The tractor is available with two different types of transmissions: a partially synchronized transmission with six forward and two reverse gears or a hydrostatic transmission with infinite forward and reverse gears. The CK20 operates with a power steering system, wet disc brakes, and offers an open operator station with ROPS for safety. It has a fuel capacity of 20 liters and a lift capacity at hitch ends of 503 kg. Overall, the CK20 is capable of handling various tasks due to its versatile attachments and design that prioritizes operator comfort and functionality.

Key Specifications

Category: Utility

Power Output: 21

Transmission: Partially synchronized

Drive Type: MFWD 4WD

Operating Weight: 1962

Fuel Type: Diesel

Image Gallery

Kioti CK20 Tractor

Kioti CK20 vs. Similar Tractors

Power Output

Below Average

Greater than 11% of similar tractors.

Hitch Capacity

Poor

Greater than 0% of similar tractors.

Operating Weight

Below Average

Greater than 16% of similar tractors.

Technical Specifications

Engine

Manufacturer: Daedong
Model: 3C093
Cooling Type: Liquid-cooled
Cylinder Orientation: Inline
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Natural
Cylinders: 3
Displacement (ci): 56.6
Bore (in): 2.95
Stroke (in): 2.76
Rated RPM: 2800
Power Output (hp): 21

Transmission

Type: Partially synchronized
Forward Gears: 6
Reverse Gears: 2
Total Gears: -

Dimensions

Length (in): 105.5
Width (in): 44.1
Height (in): 77.2
Operating Weight (lb): 1962

Power Take-Off (PTO)

PTO Type: Transmission (CK20) or live (CK20HST)
PTO Speed 1 (rpm): 540
PTO Speed 2 (rpm): 2000
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: MFWD 4WD
Steering Type: Power
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Ag, Lawn/Turf, Industrial
Manufacture - End Year: 2007
Hitch Type: Category I
Hitch Category: Category 1
Hitch Position: -
Hitch Capacity (lb): 1,110
Operator Station Type: Open with ROPS
Starter Type: Electric
Brake Type: Wet disc
Hydraulic System Type: Open center
