John Deere 955

Last Updated: June 2024

Overview

The John Deere 955 is a versatile 4WD compact utility tractor that was manufactured by John Deere from 1989 to 1998. Powered by a 1.4 L Yanmar 3TN84RJ three-cylinder liquid-cooled diesel engine with a compression ratio of 18.0:1, it provides 33 horsepower at an operating RPM range of 1400-3425. The tractor is equipped with a hydrostatic transmission offering infinite forward and reverse gears across two ranges, delivering smooth and variable speed control. The operator's station is open and includes a two-post ROPS for safety, with optional canopy and high ROPS available for additional protection and headroom. For attachments, this tractor uses a Category 1 three-point hitch with a lift capacity of 959 lbs and supports both mid and rear PTO functions, with speeds of 2100 and 540 rpm, respectively. The model features hydraulic power steering complemented with differential hydraulic wet disc brakes for effective operation and control. The open center hydraulic system ensures reliable operation of implements; it has a flow rate of 7.2 gpm. Overall, the John Deere 955 is well-suited for a variety of tasks around small farms and estates.
Show more...

Key Specifications

Category: Utility

Power Output: 33 hp

Transmission: Hydrostatic

Drive Type: 4WD

Operating Weight: 1990 lbs

Fuel Type: Diesel

John Deere 955 vs. Similar Tractors

Power Output
Below Average
Greater than 29% of similar tractors.
Hitch Capacity
Below Average
Greater than 19% of similar tractors.
Operating Weight
Below Average
Greater than 16% of similar tractors.

Technical Specifications

Engine

Manufacturer
Yanmar
Model
3TN84RJ
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Natural aspiration
Cylinders
3
Displacement (ci)
87.3 ci
Bore (in)
3.31 in
Stroke (in)
3.39 in
Rated RPM
3200
Power Output (hp)
33 hp

Transmission

Type
Hydrostatic
Forward Gears
Infinite (2-range)
Reverse Gears
Infinite (2-range)
Total Gears
-

Dimensions

Length (in)
110 in
Width (in)
50.2 in (minimum)
Height (in)
77.1 in (ROPS height)
Operating Weight (lb)
1990 lbs

Power Take-Off (PTO)

PTO Type
Independent
PTO Speed 1 (rpm)
540 rpm
PTO Speed 2 (rpm)
2100 rpm
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydraulic power
Coolant Capacity (qts)
4 qts
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
1998
Hitch Type
Three-Point Hitch
Hitch Category
Category 1
Hitch Position
Rear
Hitch Capacity (lb)
959 lbs
Operator Station Type
Open operator station with two-post ROPS
Starter Type
Electric
Brake Type
Differential hydraulic wet disc
Hydraulic System Type
Open center
