John Deere 8310T

Last Updated: July 2024

Overview

The John Deere 8310T is a track tractor, designed to provide superior traction and reduced soil compaction. With its hydrostatic steering and a full powershift transmission featuring 16 forward and 4 reverse gears, this tractor offers ample flexibility to manage a variety of tasks. At the heart of the 8310T is a liquid-cooled, turbocharged aftercooled six-cylinder diesel engine from John Deere itself, which displaces 496 ci and is rated for 227 horsepower. The cabin provides a comfortable working environment, and the machine operates efficiently with an oil capacity of 26.4 quarts and a cooling system that accommodates 35.9 quarts. Its heavyweight is supported by a balanced chassis that contributes to the unit's overall durability and performance. The tractor's specifications highlight the capabilities of John Deere's engineering in producing a machine that performs well for demanding agricultural tasks.

Key Specifications

Category: Crawler

Power Output: 227

Transmission: Full Powershift

Operating Weight: 25960

Fuel Type: Diesel

Image Gallery

John Deere 8310T Tractor

John Deere 8310T vs. Similar Tractors

Power Output

Average

Greater than 46% of similar tractors.

Operating Weight

Average

Greater than 55% of similar tractors.

Technical Specifications

Engine

Manufacturer: John Deere
Model: -
Cooling Type: Liquid-cooled
Cylinder Orientation: Vertical
Valve Configuration: OHV
Fuel Type: Diesel
Induction Type: Turbocharged aftercooled
Cylinders: 6
Displacement (ci): 496
Bore (in): 4.56
Stroke (in): 5.06
Rated RPM: 2200
Power Output (hp): 227

Transmission

Type: Full Powershift
Forward Gears: 16
Reverse Gears: 4
Total Gears: -

Dimensions

Length (in): 207
Width (in): 103.7
Height (in): 122.9
Operating Weight (lb): 25960

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: -
Drive Type: -
Steering Type: Hydrostatic
Coolant Capacity (qts): 35.9
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: -
Manufacture - End Year: -
Hitch Type: Three-Point Hitch
Hitch Category: Category 3
Hitch Position: Rear
Hitch Capacity (lb): -
Operator Station Type: Cab
Starter Type: Electric Starter
Brake Type: -
Hydraulic System Type: Pressure/Flow Compensated (PFC)

Test Results

Nebraska Tractor Test Laboratory - Test Date: April 17-May 12, 2000

Maximum Power and Fuel Consumption

Rated Engine Speed (PTO speed—1009 rpm): 206.33 HP (153.86 kW) at 2200 rpm
Fuel Consumption at Rated Engine Speed: 11.83 Gal/hr (44.77 l/h) with a fuel efficiency of 0.405 lb/hp.hr (0.246 kg/kW.h)
Maximum Power (2 hours): 235.12 HP (175.33 kW) at 1999 rpm

Drawbar Performance

Maximum Power—9th Gear: 177.43 HP (132.31 kW) with a drawbar pull of 14334 lbs (63.76 kN) and a speed of 4.64 mph (7.47 km/h)
Fuel Consumption at Maximum Power—9th Gear: 0.472 lb/hp.hr (0.287 kg/kW.h) with a fuel efficiency of 14.96 Hp.hr/gal (2.95 kW.h/l)

Torque and Engine Performance

Maximum Torque: 729 lb.-ft. (988 Nm) at 1202 rpm
Torque Rise: 48.1% with a torque rise at 1799 rpm of 36%

Hydraulic Performance

Maximum Force Exerted Through Whole Range: 15749 lbs (70.1 kN)
Pump Delivery Rate at Minimum Pressure and Rated Engine Speed: 34.7 GPM (131.4 l/min)
Hydraulic Power: 48.6 HP (36.2 kW) at delivery pressure of 2540 psi (175 bar)

Overall Efficiency

Fuel Efficiency at Rated Engine Speed (2200 rpm): 17.45 Hp.hr/gal (3.44 kW.h/l)
Fuel Consumption at Varying Power: 11.83 Gal/hr (44.77 l/h) at 2200 rpm

Nebraska Tractor Test Lab.(2000).Test 1776: John Deere 8310T Diesel 16-Speed. Lincoln, NE: Nebraska Tractor Test Laboratory. Retrieved from https://digitalcommons.unl.edu/tractormuseumlit/2203
