John Deere 8295RT

Last Updated: July 2024

Overview

The John Deere 8295RT is a powerful track tractor designed for heavy-duty agricultural operations. With a 6-cylinder, 24-valve, turbocharged and aftercooled diesel engine displacing 548 cubic inches, it delivers a maximum power output of 279.14 hp for short bursts and a rated PTO power of 242.81 hp at 2100 rpm. The tractor features both an Infinitely Variable Transmission (IVT) and a 16-speed PowerShift transmission with 3 strategic reverse gears. Its electro-hydraulic power steering system with differential steering ensures precise control, while the robust track chassis minimizes soil compaction. Weighing in at 33,660 lb, the 8295RT boasts impressive drawbar performance and hydraulic capabilities, making it well-suited for demanding tasks. Additional notable features include a wet multiple disc clutch and brake system, multiple power take-off speeds, and impressive fuel efficiency ratings.
Show more...

Key Specifications

Category: Crawler

Power Output: 279.14 (Maximum Power, 1 hour), 242.81 (Rated Power, PTO), 267.29 (Standard Power, 1000 rpm PTO)

Transmission: Full power shift, Infinitely Variable Transmission (IVT); Selective gear fixed ratio transmission

Drive Type: Track

Operating Weight: 33,660

Fuel Type: Diesel, No. 2 Diesel

Image Gallery

John Deere 8295RT Tractor John Deere 8295RT Tractor John Deere 8295RT Tractor John Deere 8295RT Tractor John Deere 8295RT Tractor John Deere 8295RT Tractor

John Deere 8295RT vs. Similar Tractors

Power Output
Excellent
Greater than 96% of similar tractors.
Operating Weight
Poor
Greater than 7% of similar tractors.

Technical Specifications

Engine

Manufacturer
John Deere
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Valve Configuration
24-valve
Fuel Type
Diesel, No. 2 Diesel
Induction Type
Turbocharged aftercooled
Cylinders
6
Displacement (ci)
548
Bore (in)
4.661
Stroke (in)
5.354
Rated RPM
2100
Power Output (hp)
279.14 (Maximum Power, 1 hour), 242.81 (Rated Power, PTO), 267.29 (Standard Power, 1000 rpm PTO)

Transmission

Type
Full power shift, Infinitely Variable Transmission (IVT); Selective gear fixed ratio transmission
Forward Gears
Infinite (IVT), 16 (PowerShift)
Reverse Gears
Infinite (IVT), 3 strategic gears (PowerShift)
Total Gears
-

Dimensions

Length (in)
223.5
Width (in)
150
Height (in)
130.8
Operating Weight (lb)
33,660

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
Track
Drive Type
Track
Steering Type
Electro-hydraulic power, differential steering
Coolant Capacity (qts)
42.3
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
III/IIIN
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Closed center pressure-flow compensated

Test Results

Nebraska Tractor Test Laboratory - Test Date: April 28 to May 12, 2010

Maximum Power and Fuel Consumption

  • Rated Engine Speed: 242.81 HP (181.06 kW) at 2100 rpm
  • Fuel Consumption at Rated Engine Speed: 13.34 Gal/hr (50.51 l/h) with a fuel efficiency of 0.386 lb/hp.hr (0.235 kg/kW.h)
  • Maximum Power (1 hour): 279.14 HP (208.16 kW) at 1749 rpm

Drawbar Performance (Unballasted)

  • Maximum Power—8th Gear: 212.62 HP (158.55 kW) with a drawbar pull of 17521 lbs (77.94 kN) and a speed of 4.55 mph (7.32 km/h), fuel efficiency of 15.87 Hp.hr/gal (3.13 kW.h/l)
  • Power at 75% Pull at Maximum Power—8th Gear: 164.59 HP (122.73 kW), with drawbar pull of 13109 lbs (58.31 kN) and a speed of 4.71 mph (7.58 km/h), fuel efficiency of 14.34 Hp.hr/gal (2.83 kW.h/l)

Torque and Engine Performance

  • Maximum Torque: 913 lb.-ft. (1238 Nm) at 1501 rpm
  • Torque Rise: 50.4%

Hydraulic Performance

  • Maximum Force Exerted: 21167 lbs (94.2 kN) at hitch points with IVN Category
  • Pump Delivery Rate: 65.0 GPM (246.1 l/min) at minimum pressure and rated engine speed
  • Hydraulic Power: 91.7 HP (68.4 kW) at delivery pressure of 2429 psi (168 bar)

Overall Efficiency

  • Fuel Efficiency at Standard PTO Speed (1000 rpm): 18.59 Hp.hr/gal (3.66 kW.h/l)
  • Fuel Consumption: 14.38 Gal/hr (54.43 l/h) at 2004 rpm



NTTL. (2010). Nebraska OECD Tractor test 1970 for John Deere 8295RT Diesel. Lincoln, NE: Nebraska Tractor Test Laboratory. Retrieved from https://digitalcommons.unl.edu/tractormuseumlit/2388
