John Deere 70F

Last Updated: June 2024

Overview

The John Deere 70F is a specialized orchard/vineyard tractor designed for use in the narrow spaces typical of these agricultural areas. Equipped with a robust 4WD (Four-Wheel Drive) chassis and a 181.2 cubic inch VM Motori D754 diesel engine, this model offers 70 horsepower and substantial torque of 154.9 lb-ft, ideal for pulling and operating specialized equipment used in orchards and vineyards. The John Deere 70F operates at a rated RPM of 2600 and features a power steering system for enhanced maneuverability. The liquid-cooled engine ensures an efficient thermal management during long working hours. The tractor's weight of 4519 lbs and measurements—142.3 inches in length and 86.6 inches in height—contribute to its stable footing and ability to navigate between tight crop rows. The transmission features 16 forward and 8 reverse gears, giving the operator a wide range of speeds to match various tasks' requirements.
Show more...

Key Specifications

Category: Agricultural, Orchard/Vineyard

Power Output: 70

Drive Type: 4WD

Operating Weight: 4519

Fuel Type: Diesel

John Deere 70F vs. Similar Tractors

Power Output
Average
Greater than 45% of similar tractors.
Operating Weight
Below Average
Greater than 24% of similar tractors.

Technical Specifications

Engine

Manufacturer
VM Motori
Model
D754
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
181.2
Bore (in)
3.7
Stroke (in)
4.21
Rated RPM
2600
Power Output (hp)
70

Transmission

Type
-
Forward Gears
16
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
142.3
Width (in)
-
Height (in)
86.6
Operating Weight (lb)
4519

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open Center
