John Deere 70A

Last Updated: June 2024

Overview

The John Deere 70A is a versatile orchard/vineyard tractor designed to perform a variety of tasks in specialized agricultural environments. This tractor features a 4x4 articulated 4WD chassis which provides enhanced maneuverability and traction on uneven terrain. It is powered by a VM Motori D703T 68hp turbocharged diesel engine that boasts a displacement of 127.1 cubic inches, and operates at a rated speed of 2600 RPM. The engine's power output is complemented by a twelve-speed transmission offering flexibility in various operational requirements. Its hydraulic dry disc clutch indicates a transmission system that is capable of handling tasks that demand precise power delivery. This tractor model does not include information regarding its hydraulic system, tire dimensions, PTO speed, and some other details, leaving those aspects to be discovered from other sources or through direct inspection.
Show more...

Key Specifications

Category: Agricultural, Orchard/Vineyard

Power Output: 68

Drive Type: 4WD

Fuel Type: Diesel

John Deere 70A vs. Similar Tractors

Power Output
Average
Greater than 42% of similar tractors.

Technical Specifications

Engine

Manufacturer
VM Motori
Model
D703T
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
3
Displacement (ci)
127.1
Bore (in)
3.7
Stroke (in)
3.94
Rated RPM
2600
Power Output (hp)
68

Transmission

Type
-
Forward Gears
12
Reverse Gears
4
Total Gears
16

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 articulated 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
