John Deere 655

Last Updated: June 2024

Overview

The John Deere 655 is a versatile compact utility tractor that was manufactured in Horicon, Wisconsin, USA from 1986 to 1990. This tractor is available in both two-wheel drive (2WD) and four-wheel drive (4WD) models to accommodate different farming and land maintenance needs. It features a reliable Yanmar 3TN66UJ three-cylinder diesel engine with a displacement of 0.7 L, providing sufficient power for various tasks. The tractor utilizes a hydrostatic transmission with infinite (2-range) speed selections which allow for easy operation and control. With an open operator station equipped with an optional canopy and a two-post ROPS for safety, it assures comfort and protection. The power is complemented by a range of features including hydrostatic power steering, differential hydraulic wet disc brakes, and a 3-point hitch system with a lift capacity of 794 lbs. The JD 655 was designed to be rugged, dependable, and easy to use, suitable for a wide variety of agricultural tasks.

Key Specifications

Category: Utility

Power Output: 16 hp

Transmission: Hydrostatic

Operating Weight: 1565 lbs (2WD) / 1635 lbs (4WD)

Fuel Type: Diesel

Lift Capacity: 794 lbs

Image Gallery

John Deere 655 Tractor

John Deere 655 vs. Similar Tractors

Power Output

Poor

Greater than 4% of similar tractors.

Hitch Capacity

Below Average

Greater than 17% of similar tractors.

Operating Weight

Excellent

Greater than 94% of similar tractors.

Technical Specifications

Engine

Manufacturer: Yanmar
Model: 3TN66UJ
Cooling Type: Liquid-cooled
Cylinder Orientation: Inline
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Natural aspirated
Cylinders: 3
Displacement (ci): 40.2 ci
Bore (in): 2.598
Stroke (in): 2.528 in
Rated RPM: 3200
Power Output (hp): 16 hp

Transmission

Type: Hydrostatic
Forward Gears: Infinite (2-range)
Reverse Gears: Infinite (2-range)
Total Gears: -

Dimensions

Length (in): 100.8 in
Width (in): 47.6 in
Height (in): 74 in
Operating Weight (lb): 1565 lbs (2WD) / 1635 lbs (4WD)

Power Take-Off (PTO)

PTO Type: Independent
PTO Speed 1 (rpm): 540 rpm
PTO Speed 2 (rpm): 2100 rpm
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x2 2WD or 4x4 MFWD 4WD
Drive Type: -
Steering Type: Hydrostatic power
Coolant Capacity (qts): 4 qts
Front Tire Diameter (in): Unknown (4.00 for 2WD / 5 for 4WD size not provided)
Front Tire Width (in): Unknown (Width not provided)
Rear Tire Diameter (in): Unknown (7.2 for 2WD/4WD size not provided)
Rear Tire Width (in): Unknown (Width not provided)
Front/Rear Rim Diameter (in): -
Tire Type: Ag: agricultural, Lawn/turf: unknown
Manufacture - End Year: 1990
Hitch Type: Three-Point Hitch
Hitch Category: Category I
Hitch Position: -
Hitch Capacity (lb): 794 lbs
Operator Station Type: Open operator station with two-post ROPS. Optional canopy.
Starter Type: Electric
Brake Type: Differential hydraulic wet disc
Hydraulic System Type: Open center
