John Deere 6500L

Last Updated: September 2024

Overview

The John Deere 6500L is a powerful orchard and vineyard tractor designed for agricultural use. It features a 2WD drive system and a partial power shift transmission with 16 forward and 16 reverse gears, giving farmers plenty of options for different tasks. The tractor is equipped with a John Deere 4045 engine, which is a 4-cylinder, turbocharged diesel engine that delivers an impressive 114 hp at 2300 rpm. This engine power is very high compared to other tractors in its class.

At 162.7 inches long and 96.1 inches tall, the 6500L is built to navigate through orchards and vineyards with ease. It has a substantial operating weight of 7,740 lb, which is above average for similar tractors. The tractor comes with agricultural tires on both front and rear, and it features a Category II hitch at the rear for attaching various implements. The 6500L also boasts a closed center pressure flow compensated hydraulic system and a comfortable cab for the operator. With its electric starter and liquid-cooled engine, this John Deere tractor is ready to tackle tough farming jobs efficiently and reliably.
Show more...

Key Specifications

Category: Orchard/Vineyard

Power Output: 114 hp (85.0 kW)

Transmission: Partial power shift

Drive Type: 2WD

Operating Weight: 7740 lb (3511 kg)

Fuel Type: Diesel

John Deere 6500L vs. Similar Tractors

Power Output

The Power Output for the John Deere 6500L is Above Average. It is greater than 83% of similar Orchard/Vineyard tractors in our database.

Horsepower distribution of Orchard/Vineyard tractors

(across 0.3K+ tractors in our database)

Operating Weight

The Operating Weight for the John Deere 6500L is Average. It is greater than 69% of similar Orchard/Vineyard tractors in our database.

Operating weight distribution of Orchard/Vineyard tractors

(across 0.3K+ tractors in our database)

Engine Displacement

The Engine Displacement for the John Deere 6500L is Above Average. It is greater than 76% of similar Orchard/Vineyard tractors in our database.

Engine displacement distribution of Orchard/Vineyard tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the John Deere 6500L is Average. It is greater than 65% of similar Orchard/Vineyard tractors in our database.

Engine rated RPM distribution of Orchard/Vineyard tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
John Deere
Model
4045
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement
276 ci (4.5 L)
Bore
4.19 in (106.4 mm)
Stroke
5.00 in (127.0 mm)
Rated RPM
2300
Power Output
114 hp (85.0 kW)

Transmission

Type
Partial power shift
Forward Gears
16
Reverse Gears
16
Total Gears
28

Drivetrain

Chassis
4x2 2WD
Drive Type
2WD
