John Deere 6410

Last Updated: July 2024

Overview

The John Deere 6410 is a 2WD or 4WD utility tractor that was part of John Deere's 6000 TEN series, manufactured in Mannheim, Germany between 1999 and 2002. The tractor is powered by a 4.5 L turbocharged diesel engine (John Deere 4045TL056), offering 104 horsepower at 2300 RPM. It hosts a variety of transmission options, all equipped with wet-disc clutches, including a fully synchronized gearbox with 12 forward and 4 reverse gears, a four-speed power shift transmission offering either 16 or 24 forward and reverse gears. With a hitch lifting capacity of over 5,900 lbs and power steering, it is well-suited for a variety of tasks on the farm or field. Optional features included a ComfortGuard cab outfitted with air conditioning for enhanced operator comfort.

Key Specifications

Category: Utility

Power Output: 104

Transmission: Fully synchronized / Four-speed power shift

Drive Type: MFWD

Operating Weight: 7607 (2WD ROPS) / 9680 (4WD Cab)

Fuel Type: Diesel

Image Gallery

John Deere 6410 Tractor

John Deere 6410 vs. Similar Tractors

Power Output

Above Average

Greater than 83% of similar tractors.

Hitch Capacity

Below Average

Greater than 12% of similar tractors.

Operating Weight

Excellent

Greater than 98% of similar tractors.

Technical Specifications

Engine

Manufacturer: John Deere
Model: 4045TL056
Cooling Type: Liquid-cooled
Cylinder Orientation: Inline
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Turbocharged
Cylinders: 4
Displacement (ci): 276
Bore (in): 4.17
Stroke (in): 5
Rated RPM: 2300
Power Output (hp): 104

Transmission

Type: Fully synchronized / Four-speed power shift
Forward Gears: 12/16/2024
Reverse Gears: 4 / 16 / 16 / 24
Total Gears: -

Dimensions

Length (in): 162.6
Width (in): 79.9
Height (in): 110.2 (ROPS) / 104.6 (Cab)
Operating Weight (lb): 7607 (2WD ROPS) / 9680 (4WD Cab)

Power Take-Off (PTO)

PTO Type: Independent
PTO Speed 1 (rpm): 540
PTO Speed 2 (rpm): 1,000
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4×4 MFWD 4WD
Drive Type: MFWD
Steering Type: Power
Coolant Capacity (qts): 11.6 (ROPS) / 14.5 (Cab)
Front Tire Diameter (in): 18 (2WD) / 24 (4WD)
Front Tire Width (in): 7.50 (2WD) / 13.6 (4WD)
Rear Tire Diameter (in): 34
Rear Tire Width (in): 18.4
Front/Rear Rim Diameter (in): -
Tire Type: Ag
Manufacture - End Year: 2002
Hitch Type: Three-Point Hitch
Hitch Category: II
Hitch Position: Rear
Hitch Capacity (lb): 5,916 lbs
Operator Station Type: Open (ROPS) / Cab (ComfortGard)
Starter Type: Electric
Brake Type: Differential hydraulic wet disc
Hydraulic System Type: Closed center pressure-flow compensating
