John Deere 6130D

Last Updated: July 2024

Overview

The John Deere 6130D is a utility tractor with a 4x4 MFWD 4WD chassis and hydrostatic power steering. It is powered by a 4-cylinder, liquid-cooled, intercooled turbocharged diesel engine (John Deere 4045H PowerTech E) with a rated power output of 111.98 hp at 2200 RPM. The transmission is a selective gear fixed ratio type with 9 forward and 9 reverse gears. Key specifications include a maximum torque of 347 lb-ft at 1500 RPM, rear tread width range of 59.5" to 79.2", front tread width range of 60.1" to 80.3", and a wheelbase of 96.5 inches. The hydraulic system has a maximum pressure of 3006 psi and a pump delivery rate of 19.4-20.7 GPM. The operating weight is 10,175 lbs with an operator and unballasted.

Key Specifications

Category: Utility

Power Output: 111.98

Transmission: Selective gear fixed ratio

Drive Type: 4WD

Operating Weight: 10175

Fuel Type: Diesel

Image Gallery

John Deere 6130D Tractor

John Deere 6130D vs. Similar Tractors

Power Output

Above Average

Greater than 89% of similar tractors.

Hitch Capacity

Above Average

Greater than 82% of similar tractors.

Operating Weight

Average

Greater than 61% of similar tractors.

Technical Specifications

Engine

Manufacturer: John Deere
Model: 4045H PowerTech E
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: 8-valve
Fuel Type: Diesel
Induction Type: Intercooled turbocharged
Cylinders: 4
Displacement (ci): 276
Bore (in): 4.2
Stroke (in): 5
Rated RPM: 2200
Power Output (hp): 111.98

Transmission

Type: Selective gear fixed ratio
Forward Gears: 9
Reverse Gears: 9
Total Gears: -

Dimensions

Length (in): 166
Width (in): 72
Height (in): 107.5 (cab), 106 (exhaust), Unknown (overall height without assumptions)
Operating Weight (lb): 10175

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: Hydrostatic power
Coolant Capacity (qts): Unknown
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Ag
Manufacture - End Year: -
Hitch Type: Three-Point Hitch
Hitch Category: II
Hitch Position: Rear
Hitch Capacity (lb): 7304 lbs (with 2 x 80 mm lift cylinders)
Operator Station Type: Cab
Starter Type: Electric Starter (12 volts inferred from Engine - Starter volts)
Brake Type: -
Hydraulic System Type: Open center

Test Results

Nebraska Tractor Test Laboratory - Test Date: March 27 to April 11, 2013

Maximum Power and Fuel Consumption

Maximum Power (1 hour): 111.98 HP (83.50 kW) at 1900 rpm
Fuel Consumption at Maximum Power: 6.27 Gal/hr (23.74 l/h) with a fuel efficiency of 0.393 lb/hp.hr (0.239 kg/kW.h) and 17.85 Hp.hr/gal (3.52 kW.h/l)
Fuel Used During Active Exhaust Regeneration: 0.53 gal (1.99 l)

Drawbar Performance

Power at 5th (B2) Gear: 93.07 HP (69.40 kW) with a drawbar pull of 5976 lbs (26.58 kN) and a speed of 5.84 mph (9.40 km/h)
Fuel Consumption at 5th (B2) Gear: 0.475 lb/hp.hr (0.289 kg/kW.h) with a fuel efficiency of 14.74 Hp.hr/gal (2.90 kW.h/l)

Torque and Engine Performance

Maximum Torque: 347 lb.-ft. (470 Nm) at 1500 rpm
Torque Rise: 38.4%
Power Increase at 1900 rpm: 6.7%

Hydraulic Performance

Maximum Force Exerted through Whole Range: 7304 lbs (32.5 kN) with lift cylinders of 2 x 80 mm
Pump Delivery Rate at Minimum Pressure and Rated Engine Speed: 20.7 GPM (78.2 l/min)
Hydraulic Power at Maximum Hydraulic Power: 29.9 HP (22.3 kW) at a delivery pressure of 2646 psi (182 bar)

NTTL. (2013). Test 2057: John Deere 6130D. Nebraska Tractor Test Laboratory, University of Nebraska-Lincoln. Retrieved from https://digitalcommons.unl.edu/tractormuseumlit/2500
