John Deere 6125E

Last Updated: June 2024

Overview

The John Deere 6125E is a robust utility tractor that is well-suited for a variety of agricultural tasks. It is powered by a 125 horsepower John Deere 6068 PowerTech turbocharged diesel engine with a displacement of 414.4 cubic inches, designed to deliver consistent performance for demanding work. The tractor's hydrostatic power steering and 4-wheel drive chassis provide excellent maneuverability and traction. It comes with a fully synchronized 12-forward and 4-reverse speed transmission, catering to a wide range of speed requirements for different applications. At a weight of 10,120 lbs and a height of 107.9 inches, it presents as a substantial machine capable of heavy-duty tasks. Moreover, it is equipped with a load sensing hydraulic system and has standard agricultural tires; front: 18.4-34 and rear: 14.9-24.

Key Specifications

Category: Utility

Power Output: 125

Transmission: Fully synchronized

Drive Type: 4WD

Operating Weight: 10,120

Fuel Type: Diesel

Image Gallery

John Deere 6125E Tractor

John Deere 6125E vs. Similar Tractors

Power Output

Above Average

Greater than 88% of similar tractors.

Operating Weight

Poor

Greater than 5% of similar tractors.

Technical Specifications

Engine

Manufacturer: John Deere
Model: 6068 PowerTech
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Turbocharged
Cylinders: 6
Displacement (ci): 414.4
Bore (in): 4.19
Stroke (in): 5
Rated RPM: 2300
Power Output (hp): 125

Transmission

Type: Fully synchronized
Forward Gears: 12
Reverse Gears: 4
Total Gears: -

Dimensions

Length (in): 193.7
Width (in): -
Height (in): 107.9
Operating Weight (lb): 10,120

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: Hydrostatic power
Coolant Capacity (qts): -
Front Tire Diameter (in): 34
Front Tire Width (in): 18.4
Rear Tire Diameter (in): 24
Rear Tire Width (in): 14.9
Front/Rear Rim Diameter (in): -
Tire Type: Ag
Manufacture - End Year: -
Hitch Type: Category II
Hitch Category: Category 3
Hitch Position: Rear
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: 12 volt
Brake Type: -
Hydraulic System Type: Load sensing
