John Deere 6115D

Last Updated: July 2024

Overview

The John Deere 6115D is a 2WD/4WD utility tractor from the 6D series, manufactured by Industrius John Deere in Saltillo, Mexico. It is equipped with a 4.5 L four-cylinder turbocharged intercooled diesel engine with a rated power output of 101.83 hp at 2200 RPM and a compression ratio of 19.0:1. The engine displacement is 276 cu in with a bore of 4.19 in and stroke of 5 in. The tractor features a 9-speed transmission with power shuttle and 9 reverse gears. Key performance figures include a maximum torque of 316 lb-ft at 1499 RPM with a 39.4% torque rise, and a hydraulic system capable of exerting up to 7304 lbs of force. The 6115D has a regenerative particulate filter and runs on No. 2 Diesel fuel. It has an unladen weight of 9770 lb.

Key Specifications

Category: Utility

Power Output: 101.83

Transmission: Partially synchronized with power shuttle or Top Shaft Synchronized (TSS)

Drive Type: 2WD or 4WD

Operating Weight: 9770

Fuel Type: No. 2 Diesel

Image Gallery

John Deere 6115D Tractor

John Deere 6115D vs. Similar Tractors

Power Output

Above Average

Greater than 87% of similar tractors.

Hitch Capacity

Excellent

Greater than 96% of similar tractors.

Operating Weight

Average

Greater than 61% of similar tractors.

Technical Specifications

Engine

Manufacturer: Industrius John Deere
Model: 4045H PowerTech E
Cooling Type: Liquid-cooled
Cylinder Orientation: Inline
Valve Configuration: -
Fuel Type: No. 2 Diesel
Induction Type: Turbocharged intercooled
Cylinders: 4
Displacement (ci): 276
Bore (in): 4.19
Stroke (in): 5
Rated RPM: 2200
Power Output (hp): 101.83

Transmission

Type: Partially synchronized with power shuttle or Top Shaft Synchronized (TSS)
Forward Gears: 9
Reverse Gears: 9 (Power shuttle)
Total Gears: -

Dimensions

Length (in): 168.1 (2WD) or 165.7 (4WD)
Width (in): 71.7
Height (in): 107.5
Operating Weight (lb): 9770

Power Take-Off (PTO)

PTO Type: Independent with dry disc clutch
PTO Speed 1 (rpm): 540 at 2085 engine rpm or 1000 at 2066 engine rpm
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x2 2WD or 4x4 MFWD 4WD
Drive Type: 2WD or 4WD
Steering Type: Hydrostatic power
Coolant Capacity (qts): 17.4
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Ag
Manufacture - End Year: 2012
Hitch Type: -
Hitch Category: Category II
Hitch Position: -
Hitch Capacity (lb): 7304
Operator Station Type: Folding 2-post ROPS or cab with heat and A/C
Starter Type: Electric
Brake Type: Independent mechanical wet disc
Hydraulic System Type: Open center

Test Results

Nebraska Tractor Test Laboratory - Test Date: June 15-19, 2009

Maximum Power and Fuel Consumption

Rated Engine Speed: 99.05 HP (73.86 kW) at 2100 rpm
Fuel Consumption at Rated Speed: 6.35 Gal/hr (24.02 l/h) with a fuel efficiency of 0.452 lb/hp.hr (0.275 kg/kW.h)
Maximum Power at Standard PTO Speed: 99.37 HP (74.10 kW) at 2066 rpm
Fuel Consumption at Standard PTO Speed: 6.28 Gal/hr (23.75 l/h) with a fuel efficiency of 0.445 lb/hp.hr (0.271 kg/kW.h)

Drawbar Performance

Power in 5th (B2) Gear: 80.89 HP (60.32 kW) with a drawbar pull of 5807 lbs (25.83 kN) and a speed of 5.23 mph (8.41 km/h)
Fuel Consumption in 5th Gear: 0.550 lb/hp.hr (0.334 kg/kW.h) with a fuel efficiency of 12.83 Hp.hr/gal (2.53 kW.h/l)
Power Increase: 0.3% at 2066 rpm

Torque and Engine Performance

Maximum Torque: 315 lb.-ft. (427 Nm) at 1400 rpm
Torque Rise: 27.1%
Torque Rise at 1700 rpm: 19%

Hydraulic Performance

Maximum Force Exerted: 6841 lbs (30.4 kN) through whole range
Pump Delivery Rate at Minimum Pressure: 18.4 GPM (69.7 l/min)
Hydraulic Power: 20.6 HP (15.4 kW) at delivery pressure of 2602 psi (179 bar)

Overall Efficiency

Fuel Efficiency at Rated Engine Speed: 15.61 Hp.hr/gal (3.08 kW.h/l)
Fuel Efficiency at Standard PTO Speed: 15.84 Hp.hr/gal (3.12 kW.h/l)

NTTL.(2009). Test 1949: John Deere 6115D Diesel. Nebraska Tractor Test Laboratory. Retrieved from https://digitalcommons.unl.edu/tractormuseumlit/2350
