John Deere 6100D Cab

Last Updated: June 2024

Overview

The John Deere 6100D Cab is a tractor that features a PowrReverser transmission, offering 9 forward and 9 reverse gears, enabling versatile maneuvering. It is powered by a turbocharged engine manufactured by the company denoted as "2240," which provides a gross power output of 98.9 horsepower and an engine displacement of 276 cubic inches. The engine achieves its rated power at 2100 RPM and is connected to a PTO that delivers 82 hp. Ground clearance is a comfortable 18 inches, complementing the tractor's wheelbase of 7.8 feet. This machine is designed to handle challenging tasks, with a 3 point hitch lift capacity of 6930 lbs at 24 inches, a robust operating weight of 7936.7 lbs, and a capable hydraulic system that includes 2 remote control valves and a pump flow rate of 17.6 gallons per minute. Fuel capacity is ample at 41.8 gallons. The tractor's practical design is showcased by tire configurations that include 10.00-16 6PR F2 tires at the front and 18.4-34 8PR R1 at the rear, ensuring traction and stability across various terrains.
Show more...

Key Specifications

Power Output: 98.9

Transmission: PowrReverser

Operating Weight: 7936.7

Lift Capacity: 6930 lbs

Technical Specifications

Engine

Manufacturer
2240
Model
-
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
-
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
276
Bore (in)
-
Stroke (in)
-
Rated RPM
2100
Power Output (hp)
98.9

Transmission

Type
PowrReverser
Forward Gears
9
Reverse Gears
9
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
7936.7

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Front: F2, 6PR | Rear: R1, 8PR
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
6930 lbs
Operator Station Type
Cab
Starter Type
-
Brake Type
-
Hydraulic System Type
-
