John Deere 50R

Last Updated: June 2024

Overview

The John Deere 50R is a versatile orchard/vineyard tractor that offers a reliable solution for various operations in orchard management. Featuring a robust 4x4 MFWD 4WD chassis, the 50R ensures excellent traction and performance in a variety of conditions. At its heart is a VM Motori D703 49 hp diesel engine, which provides ample power while maintaining efficiency with a liquid-cooling system. The engine's displacement is 127.1 ci, with a bore of 3.70 inches and stroke of 3.94 inches, rated for a maximum of 2600 RPM. It generates 49 horsepower capable of delivering the torque needed for demanding tasks. This workhorse comes with a transmission offering 16-speed forward and reverse gears, matched with a 280mm hydraulic dry disc clutch, ensuring smooth control and versatile range of speeds. With a rated torque at 1200 RPM and essential electric start feature, John Deere 50R is a practical and efficient tractor designed to meet the unique needs of orchard and vineyard farming.
Show more...

Key Specifications

Category: Agricultural, Orchard/Vineyard

Power Output: 49

Drive Type: 4WD

Fuel Type: Diesel

John Deere 50R vs. Similar Tractors

Power Output
Below Average
Greater than 20% of similar tractors.

Technical Specifications

Engine

Manufacturer
VM Motori
Model
D703
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
127.1
Bore (in)
3.7
Stroke (in)
3.94
Rated RPM
2600
Power Output (hp)
49

Transmission

Type
-
Forward Gears
16
Reverse Gears
-
Total Gears
32

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
