John Deere 5093E

Last Updated: June 2024

Overview

The John Deere 5093E is a versatile 4WD utility tractor that was produced by John Deere from 2008 to 2012. This model comes equipped with a 4.5L, 276 ci PowerTech 4045 four-cylinder turbocharged diesel engine capable of delivering 93 hp and a rated RPM of 2400. The 5093E model includes features such as a hydrostatic power steering system, independent hydraulic wet disc brakes, a Cab (standard) operator station, and a 33.5 US gallon fuel tank capacity. Its chassis is designed with a 4x4 MFWD 4WD configuration, and the tractor provides a 12-speed partially synchronized transmission with 12 forward and reverse gears, allowing for efficient operation and maneuverability in a wide range of tasks. The John Deere 5093E is compatible with a variety of attachments, enhancing its utility for agricultural, landscaping, and various other tasks. Additional specifications such as high-performance hydraulics, a hitch with a lift capacity of 3,220 lbs, and a convenient operator station makes this tractor a reliable workhorse for many on-farm jobs.
Show more...

Key Specifications

Category: Utility

Power Output: 93

Transmission: Partially synchronized

Drive Type: 4WD

Operating Weight: 7,385

Fuel Type: Diesel

John Deere 5093E vs. Similar Tractors

Power Output
Above Average
Greater than 78% of similar tractors.
Hitch Capacity
Poor
Greater than 8% of similar tractors.
Operating Weight
Poor
Greater than 4% of similar tractors.

Technical Specifications

Engine

Manufacturer
John Deere
Model
PowerTech 4045
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
276
Bore (in)
4.19
Stroke (in)
5
Rated RPM
2400
Power Output (hp)
93

Transmission

Type
Partially synchronized
Forward Gears
12
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
147.6
Width (in)
64.6
Height (in)
98.4
Operating Weight (lb)
7,385

Power Take-Off (PTO)

PTO Type
Independent with mechanical clutch
PTO Speed 1 (rpm)
540
PTO Speed 2 (rpm)
540E or 1000 (optional)
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag (Agricultural)
Manufacture - End Year
2012
Hitch Type
Category II/I
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
3,220 lbs at 24 in
Operator Station Type
Cab (standard)
Starter Type
Electric
Brake Type
Independent hydraulic wet disc
Hydraulic System Type
Open center
