John Deere 4510

Last Updated: June 2024

Overview

The John Deere 4510 is a versatile compact utility tractor, part of the 4000 Ten Compact series, produced between 2003 and 2004 in Augusta, Georgia, USA. It hosts a four-cylinder Yanmar 4TNE84 diesel engine, capable of delivering 38.4 horsepower with a displacement of 122 cubic inches, at a rated speed of 2600 RPM. Customers have the option between a SyncShift transmission offering nine forward and three reverse gears or a PowrReverser transmission with twelve gears in both directions. It features power steering, wet disc brakes, an open operator station with ROPS, and a hydraulic system operating through an open center design. This model was designed for a range of agricultural tasks and is capable of adapting to various attachments that increase its utility across different jobs.
Show more...

Key Specifications

Category: Utility

Power Output: 38.4

Transmission: SyncShift (partially synchronized) or PowrReverser (Power shuttle)

Operating Weight: 3450

Fuel Type: Diesel

John Deere 4510 vs. Similar Tractors

Power Output
Average
Greater than 35% of similar tractors.
Operating Weight
Below Average
Greater than 30% of similar tractors.

Technical Specifications

Engine

Manufacturer
Yanmar
Model
4TNE84
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Natural Aspiration
Cylinders
4
Displacement (ci)
122
Bore (in)
3.307
Stroke (in)
3.543
Rated RPM
2600
Power Output (hp)
38.4

Transmission

Type
SyncShift (partially synchronized) or PowrReverser (Power shuttle)
Forward Gears
9 (SyncShift) or 12 (PowrReverser)
Reverse Gears
3 (SyncShift) or 12 (PowrReverser)
Total Gears
-

Dimensions

Length (in)
135
Width (in)
62
Height (in)
91.6
Operating Weight (lb)
3450

Power Take-Off (PTO)

PTO Type
Independent
PTO Speed 1 (rpm)
540 (Rear PTO), 2100 (Mid PTO)
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD or 4x4 MFWD 4WD
Drive Type
-
Steering Type
Power
Coolant Capacity (qts)
6.4
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
2004
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Open operator station with ROPS
Starter Type
Electric
Brake Type
Wet disc
Hydraulic System Type
Open center
