John Deere 4410

Last Updated: June 2024

Overview

The John Deere 4410 is a versatile compact utility tractor that was part of the 4000 Ten Compact series. Designed for a variety of tasks, it's powered by a reliable Yanmar 3TNE88 three-cylinder diesel engine, offering a dependable 34.6 horsepower at 2600 RPM. This model accommodates two transmission options: the 12-speed power shuttle or the eHydro hydrostatic transmission with infinite three-range forward and reverse gears. Riders get the comfort and control provided by power steering and the stopping power of wet disc brakes. Manufactured between 2002 and 2004 in Augusta, Georgia, USA, it comes equipped with a Category I three-point hitch with a lift capacity of 2,200 lbs at 24 inches behind the link arms. Standard features include an independent PTO with speeds of 540 and 2100 RPM for middle PTO. This model is known for its durability and efficiency in a range of agricultural tasks.

Key Specifications

Category: Utility

Power Output: 34.6

Transmission: Multiple options: Power shuttle or Hydrostatic

Drive Type: MFWD 4WD

Operating Weight: 2899.1

Fuel Type: Diesel

Image Gallery

John Deere 4410 Tractor

John Deere 4410 vs. Similar Tractors

Power Output

Below Average

Greater than 30% of similar tractors.

Hitch Capacity

Poor

Greater than 3% of similar tractors.

Operating Weight

Below Average

Greater than 24% of similar tractors.

Technical Specifications

Engine

Manufacturer: Yanmar
Model: 3TNE88
Cooling Type: Liquid-cooled
Cylinder Orientation: Inline
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Natural aspirated
Cylinders: 3
Displacement (ci): 99.1
Bore (in): 3.46
Stroke (in): 3.54
Rated RPM: 2600
Power Output (hp): 34.6

Transmission

Type: Multiple options: Power shuttle or Hydrostatic
Forward Gears: 12 (Power shuttle) or Infinite (3-range) (Hydrostatic)
Reverse Gears: 12 (Power shuttle) or Infinite (3-range) (Hydrostatic)
Total Gears: -

Dimensions

Length (in): 117
Width (in): 50
Height (in): 82.4 (with fixed ROPS)
Operating Weight (lb): 2899.1

Power Take-Off (PTO)

PTO Type: Independent
PTO Speed 1 (rpm): 540
PTO Speed 2 (rpm): 2100 (Middle PTO)
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: MFWD 4WD
Steering Type: Power
Coolant Capacity (qts): 6
Front Tire Diameter (in): 14
Front Tire Width (in): -
Rear Tire Diameter (in): 24
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Agricultural
Manufacture - End Year: 2004
Hitch Type: Three-Point Hitch
Hitch Category: Category I
Hitch Position: Rear
Hitch Capacity (lb): 2,200 lbs (at 24 in)
Operator Station Type: Two-post ROPS or foldable ROPS (optional)
Starter Type: Electric
Brake Type: Wet disc
Hydraulic System Type: Open center
