John Deere 410E

Last Updated: June 2024

Overview

The John Deere 410E is a versatile backhoe loader tractor that was in production from 1997 to 2001. It offers a choice between 2WD (4x2) and 4WD (4x4 MFWD) options, providing flexibility for different types of terrain and applications. Powered by the John Deere 4045T diesel engine, it delivers a power output of 90 HP and has a displacement of 276 cubic inches. The engine is turbocharged and operates at an optimal rated RPM of 2200. The tractor features 4 forward and reverse gears, hydrostatic power steering, and hydraulic wet disc brakes. It has the capability to work with industrial tires and can operate at considerable lengths, widths, and heights. With the presence of a ROPS canopy or a Cab, operator comfort and safety are considered in its design. However, specifics about the type of transmission, drive type, and PTO speeds were not provided within the data set.

Key Specifications

Category: Specialized, Backhoe Loader

Power Output: 90

Operating Weight: 14,991 (2WD ROPS) / 17,505 (4WD Cab)

Fuel Type: Diesel

Image Gallery

John Deere 410E Tractor

John Deere 410E vs. Similar Tractors

Power Output

Above Average

Greater than 88% of similar tractors.

Technical Specifications

Engine

Manufacturer: John Deere
Model: 4045T
Cooling Type: Liquid-cooled
Cylinder Orientation: Inline
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Turbocharged
Cylinders: 4
Displacement (ci): 276
Bore (in): 4.17
Stroke (in): 5
Rated RPM: 2200
Power Output (hp): 90

Transmission

Type: -
Forward Gears: 4
Reverse Gears: 4
Total Gears: -

Dimensions

Length (in): 286.6
Width (in): 85.8
Height (in): 110.6
Operating Weight (lb): 14,991 (2WD ROPS) / 17,505 (4WD Cab)

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x2 2WD or 4x4 MFWD 4WD
Drive Type: -
Steering Type: Hydrostatic power
Coolant Capacity (qts): 17
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Industrial
Manufacture - End Year: 2001
Hitch Type: -
Hitch Category: Category 3
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: ROPS canopy or Cab
Starter Type: Electric
Brake Type: Hydraulic wet disc
Hydraulic System Type: Pressure compensated load sensing (PCLS)
