John Deere 300D

Last Updated: June 2024

Overview

The John Deere 300D is a robust backhoe loader tractor designed for a variety of tasks in construction and agriculture. This model was manufactured by John Deere from 1991 to 2001 and can be configured as either two-wheel drive (2WD) or four-wheel drive (4WD) to suit different terrain and applications. It is powered by the John Deere 4039D engine, a reliable 3.9 L, four-cylinder diesel engine providing 60 HP at 2200 RPM and an impressive torque output of 171.7 ft·lb. With a substantial fuel tank holding 28 US gallons, lengthy operations can be undertaken with fewer interruptions for refueling. Hydrostatic power steering and differential hydraulic wet disc brakes ensure smooth and responsive handling. Its helical gear, synchronized collar shift transmission with hydraulic reverser offers four gears in both forward and reverse directions to optimize speed and maneuverability in diverse working conditions. The 300D's cab design brings comfort and protection for operators while on demanding job sites.
Show more...

Key Specifications

Category: Specialized, Backhoe Loader

Power Output: 60

Transmission: Helical gear, synchronized collar shift with hydraulic reverser

Operating Weight: 12,202

Fuel Type: Diesel

John Deere 300D vs. Similar Tractors

Power Output
Average
Greater than 40% of similar tractors.
Operating Weight
Poor
Greater than 10% of similar tractors.

Technical Specifications

Engine

Manufacturer
John Deere
Model
4039D
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Natural aspirated
Cylinders
4
Displacement (ci)
239
Bore (in)
4.19
Stroke (in)
4.33
Rated RPM
2200
Power Output (hp)
60

Transmission

Type
Helical gear, synchronized collar shift with hydraulic reverser
Forward Gears
4
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
270.1
Width (in)
91.3
Height (in)
105.5
Operating Weight (lb)
12,202

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD or 4x4 MFWD 4WD
Drive Type
-
Steering Type
Hydrostatic power
Coolant Capacity (qts)
17
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Industrial
Manufacture - End Year
2001
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Cab (standard)
Starter Type
Electric
Brake Type
Differential hydraulic wet disc
Hydraulic System Type
-
