John Deere 2446F

Last Updated: June 2024

Overview

The John Deere 2446F is an orchard/vineyard tractor emphasized by its 70 hp turbocharged liquid-cooled three-cylinder diesel engine. With a 179 ci displacement and an engine rated at 2300 RPM, it provides substantial power and torque for demanding agricultural tasks. It features a synchronized transmission with 16 forward and 8 reverse gears, combined with a 4WD chassis and power steering for maneuverability in varied terrain. The tractor’s size is suited for orchard work, with an overall length of 130.3 inches and an operating weight of 4960 lbs. The equipped standard tires support its duties, with agriculture specified for optimal field performance. The addition of an open-center hydraulic system facilitates a range of attachments and implements. Note the height varies with the inclusion of ROPS at 85.2 inches or just to the steering wheel at 54.3 inches. This specific details, and operational capacities frame the John Deere 2446F as a capable and specialized agricultural machine.
Show more...

Key Specifications

Category: Agricultural, Orchard/Vineyard

Power Output: 70

Transmission: Synchronized

Drive Type: 4WD

Operating Weight: 4960

Fuel Type: Diesel

John Deere 2446F vs. Similar Tractors

Power Output
Average
Greater than 45% of similar tractors.
Operating Weight
Below Average
Greater than 29% of similar tractors.

Technical Specifications

Engine

Manufacturer
John Deere
Model
3029
Cooling Type
Liquid
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
3
Displacement (ci)
179
Bore (in)
4.19
Stroke (in)
4.33
Rated RPM
2300
Power Output (hp)
70

Transmission

Type
Synchronized
Forward Gears
16
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
130.3
Width (in)
-
Height (in)
85.2 (with ROPS), 54.3 (to steering wheel)
Operating Weight (lb)
4960

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
Three-Point Hitch (Types I and II)
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open Center
