John Deere 2250

Last Updated: June 2024

Overview

The John Deere 2250 is a versatile utility tractor designed for various agricultural tasks. Equipped with a powerful 62 hp, 4-cylinder, liquid-cooled diesel engine, it provides ample power for medium-duty work. With a displacement of 239.2 cubic inches and an engine rated at 2300 rpm, this tractor is built to last and handle intense farming activities. The Syncro-Range and Hi-Lo transmission offer a total of 16 forward and 8 reverse gears and relies on hydraulic clutch engagement for smooth transitions. The tractor's steering is powered, assisting in maneuverability. It's built with an open-operator station cab, offering protection from the elements. Although the specific dimensions for tire diameter and width are not provided, the tractor's length is 165.1 inches and width is 73.3 inches, giving it a substantial presence. The exact operating weight varies between 7077 to 8157 pounds, depending on the configuration. The versatile hydraulic system is a closed-center constant pressure type which enhances the tractor's productivity in various field operations. However, information about the specific tire types, brake system, PTO speeds, and cooling capacity is not available.
Show more...

Key Specifications

Category: Utility

Power Output: 62

Transmission: Syncro-Range, Hi-Lo, Two-speed power shift

Operating Weight: 7077 to 8157

Fuel Type: Diesel

John Deere 2250 vs. Similar Tractors

Power Output
Average
Greater than 59% of similar tractors.
Operating Weight
Excellent
Greater than 91% of similar tractors.

Technical Specifications

Engine

Manufacturer
John Deere
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
239.2
Bore (in)
4.19
Stroke (in)
4.33
Rated RPM
2300
Power Output (hp)
62

Transmission

Type
Syncro-Range, Hi-Lo, Two-speed power shift
Forward Gears
16
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
165.1
Width (in)
73.3
Height (in)
-
Operating Weight (lb)
7077 to 8157

Power Take-Off (PTO)

PTO Type
Optional Transmission or Live PTO
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
Power Assist
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
II
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
Electric Starter
Brake Type
-
Hydraulic System Type
Closed-center constant pressure
