John Deere 2141

Last Updated: June 2024

Overview

The John Deere 2141 is a utility tractor that features a solid build and straightforward functionality, catering to a range of tasks from farming to grounds maintenance. With its traditional 4x2 2WD chassis propelled by a 76.4 horsepower diesel engine, it provides ample power for numerous agricultural applications. The engine, made by ADE, is a 4-cylinder liquid-cooled diesel engine with a displacement of 235.6 cubic inches that operates at a rated RPM of 2300. Transmission-wise, the tractor offers 8 forward gears and 4 reverse gears, suitable for various speed requirements during operation. Hydrostatic power steering adds to the ease of maneuverability, allowing for precise and less strenuous steering. This model has a substantial operating weight ranging from 7800 pounds for the 2WD version to 8700 pounds for an assumed 4WD variant, indicating robustness and stability. The electric starter system ensures a reliable start. While comprehensive specifications are not fully available, the data provided underline the tractor's robust nature and capability to handle demanding tasks.
Show more...

Key Specifications

Category: Utility

Power Output: 76.4

Drive Type: 2WD

Operating Weight: 7800 (2WD) / 8700 (4WD)

Fuel Type: Diesel

John Deere 2141 vs. Similar Tractors

Power Output
Average
Greater than 69% of similar tractors.
Operating Weight
Excellent
Greater than 98% of similar tractors.

Technical Specifications

Engine

Manufacturer
ADE
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
235.6
Bore (in)
3.875
Stroke (in)
5
Rated RPM
2300
Power Output (hp)
76.4

Transmission

Type
-
Forward Gears
8
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
7800 (2WD) / 8700 (4WD)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric Starter
Brake Type
-
Hydraulic System Type
-
