John Deere 1641

Last Updated: June 2024

Overview

The John Deere 1641 is a utility tractor designed for various agricultural tasks. It is equipped with a 4x2 2WD chassis and relies on manual steering to navigate through farm work. Under the hood, it boasts an ADE model diesel engine with four cylinders and a liquid cooling system, ensuring a stable and reliable performance. With an engine displacement of 235.6 cubic inches and a power output of 61.7 horsepower at 2300 RPM, it can handle a variety of tasks with ease. The tractor’s transmission provides eight forward and four reverse gears, offering the operator a range of speeds to adapt to different working conditions. The versatility and operating weight that ranges between 7,409 to 8,004 pounds signifies a solid and sturdy machine capable of substantial work. However, further details on the tractor’s dimensions, tire specifications, and additional features are not specified in the provided data.
Show more...

Key Specifications

Category: Utility

Power Output: 61.7

Drive Type: 2WD

Operating Weight: 7409 to 8004

Fuel Type: Diesel

John Deere 1641 vs. Similar Tractors

Power Output
Average
Greater than 58% of similar tractors.
Operating Weight
Excellent
Greater than 91% of similar tractors.

Technical Specifications

Engine

Manufacturer
-
Model
ADE
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
235.6
Bore (in)
3.875
Stroke (in)
5
Rated RPM
2300
Power Output (hp)
61.7

Transmission

Type
-
Forward Gears
8
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
7409 to 8004

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Manual
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric Starter (Based on 12 volts system)
Brake Type
-
Hydraulic System Type
-
