Jinma JM-704

Last Updated: September 2024

Overview

The Jinma JM-704 is a powerful 4-wheel drive tractor built for tough farm work. It has a strong 70 horsepower diesel engine with 4 cylinders. This engine is liquid-cooled, which helps it run smoothly in hot weather. The tractor has a manual transmission with 8 forward gears and 2 reverse gears, giving the driver good control over speed and power.

This tractor is big and sturdy. It's about 160 inches long, 76 inches wide, and 101 inches tall. It weighs 7,034 pounds, which helps it grip the ground well. The JM-704 has big agricultural tires, with 24-inch front tires and 30-inch rear tires. These tires are great for working in fields. The tractor also has a Category II hitch at the back, which lets it connect to many different farm tools. With its strong build and features, the Jinma JM-704 is ready to handle a wide range of farming tasks.
Show more...

Key Specifications

Power Output: 70 hp (52.2 kW)

Transmission: Manual

Drive Type: 4WD

Operating Weight: 7034 lb (3191 kg)

Fuel Type: Diesel

Jinma JM-704 vs. Similar Tractors

Power Output

The Power Output for the Jinma JM-704 is Average. It is greater than 55% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 6.6K+ tractors in our database)

Operating Weight

The Operating Weight for the Jinma JM-704 is Average. It is greater than 59% of similar Utility tractors in our database.

Operating weight distribution of Utility tractors

(across 6.4K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the Jinma JM-704 is Average. It is greater than 34% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
Jinma
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Cylinders
4
Rated RPM
2200
Power Output
70 hp (52.2 kW)

Transmission

Type
Manual
Forward Gears
8
Reverse Gears
2
Total Gears
10

Drivetrain

Chassis
4x4 MFWD 4WD
Drive Type
4WD
