Iseki TU120

Last Updated: September 2024

Overview

The Iseki TU120 is a compact utility tractor designed for small farms and light-duty work. It features a 2-wheel drive system and a gear transmission with 6 forward and 2 reverse speeds. This tractor is powered by a Mitsubishi K3A engine, which is a 3-cylinder, liquid-cooled diesel engine.

The TU120's engine has a displacement of 47.2 cubic inches, which is below average compared to other tractors. It produces 11.8 horsepower at 2500 RPM, making it suitable for basic tasks around the farm. The tractor's compact size, measuring 89.6 inches long, 39.4 inches wide, and 66.3 inches tall, allows it to maneuver easily in tight spaces. With an operating weight of 1268 pounds, it's lighter than most tractors, making it easy to transport and reducing soil compaction.

This Iseki model comes with agricultural tires on both front and rear wheels, providing good traction for field work. It has an electric starter for easy operation and a liquid cooling system with a 5.8-quart coolant capacity. The TU120 is a basic, no-frills tractor that's well-suited for small-scale farming operations and property maintenance.
Show more...

Key Specifications

Category: Utility

Power Output: 12 hp (8.8 kW)

Transmission: Gear

Drive Type: 2WD

Operating Weight: 1268 lb (575 kg)

Fuel Type: Diesel

Iseki TU120 vs. Similar Tractors

Power Output

The Power Output for the Iseki TU120 is Poor. It is greater than 1% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 4.7K+ tractors in our database)

Operating Weight

The Operating Weight for the Iseki TU120 is Poor. It is greater than 2% of similar Utility tractors in our database.

Operating weight distribution of Utility tractors

(across 4.4K+ tractors in our database)

Engine Displacement

The Engine Displacement for the Iseki TU120 is Poor. It is greater than 2% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the Iseki TU120 is Average. It is greater than 61% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
K3A
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement
47 ci (0.8 L)
Bore
2.56 in (65.0 mm)
Stroke
3.07 in (78.0 mm)
Rated RPM
2500
Power Output
12 hp (8.8 kW)

Transmission

Type
Gear
Forward Gears
6
Reverse Gears
2

Drivetrain

Chassis
4x2 2WD
Drive Type
2WD
