Iseki TM3245

Last Updated: June 2024

Overview

The Iseki TM3245 is a compact utility tractor designed for a variety of tasks. Its 22.3 horsepower diesel engine and hydrostatic power steering make it suitable for small scale farming, landscaping, and other utility tasks. With a 4x4 MFWD 4WD chassis and a choice of gear or hydrostatic transmission, this tractor offers flexibility for different working conditions. The tractor's engine, an Iseki E3112, is a three-cylinder, liquid-cooled diesel engine with a displacement of 68.5 cubic inches and a bore/stroke of 3.08 by 3.07 inches, running at a rated 2500 RPM. It possesses 8 speeds in both forward and reverse directions for its gear-type transmission or an infinite (3-range) option for the hydrostatic transmission, allowing for precise speed control. Wheelbase measures at 61.42 inches, and the operating weight is 1819 lbs, ensuring stability during use. Details about the tractor's hitch type and lift capacity are not provided, nor are the PTO speed details or brake system specified.

Key Specifications

Category: Utility

Power Output: 22.3

Transmission: Gear and Hydrostatic

Drive Type: 4WD

Operating Weight: 1819

Fuel Type: Diesel

Image Gallery

Iseki TM3245 Tractor

Iseki TM3245 vs. Similar Tractors

Power Output

Below Average

Greater than 13% of similar tractors.

Operating Weight

Below Average

Greater than 14% of similar tractors.

Technical Specifications

Engine

Manufacturer: Iseki
Model: E3112
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Naturally aspirated
Cylinders: 3
Displacement (ci): 68.5
Bore (in): 3.08
Stroke (in): 3.07
Rated RPM: 2500
Power Output (hp): 22.3

Transmission

Type: Gear and Hydrostatic
Forward Gears: 8 forward
Reverse Gears: 8 reverse
Total Gears: -

Dimensions

Length (in): 110.4
Width (in): 43.7
Height (in): -
Operating Weight (lb): 1819

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: hydrostatic power
Coolant Capacity (qts): -
Front Tire Diameter (in): Impossible to determine given date format
Front Tire Width (in): Impossible to determine given date format
Rear Tire Diameter (in): 18
Rear Tire Width (in): 9.5
Front/Rear Rim Diameter (in): Impossible to determine given date format for Ag; 12 for Lawn/turf front; Unknown for Lawn/turf rear
Tire Type: Ag: Unknown; Lawn/turf: Unknown
Manufacture - End Year: -
Hitch Type: -
Hitch Category: I
Hitch Position: Rear
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: Electric
Brake Type: -
Hydraulic System Type: Open center
