Iseki TM18

Last Updated: June 2024

Overview

The Iseki TM18 is a tractor designed with versatility in mind. Boasting an 18 horsepower Iseki E3112, 3-cylinder diesel engine, it is capable of delivering the power needed for a variety of tasks. The tractor is equipped with multiple transmission options, including gear, creeper, and hydrostatic types, which offer a range of forward and reverse gears - from 6 gears in its simplest form (gear type) to infinite (3-range) gears with the hydrostatic transmission. This allows for excellent adaptability in changing work conditions. The liquid-cooling system ensures the engine operates efficiently even under heavy workloads. With dry disc clutches and power steering, the TM18 enhances maneuverability and ease of control. The tractor's compact dimensions - 87 inches in length, 40.6 inches in width, and a height of 72.1 inches - make it suitable for a variety of tasks, from fieldwork to orchard maintenance. It is also relatively lightweight, with an operating weight starting at 1466 lbs (gear transmission). With a 12-inch front tire diameter and an agricultural tire type, the TM18 is geared mostly towards farming endeavors, though specific tire widths and rim diameters are not discernible from the provided data. Additional specifications like the hitch type indicate it's a Type I category, although the full capability of the hitch system and hydraulic features remain unknown. The narrative above is framed for users that own the TM18 and are already familiar with its offerings, emphasizing its specifications and usability.
Show more...

Key Specifications

Power Output: 18

Transmission: Gear, Creeper, Hydrostatic

Operating Weight: 1466

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Iseki
Model
E3112
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
68.5
Bore (in)
3.08
Stroke (in)
3.07
Rated RPM
2500
Power Output (hp)
18

Transmission

Type
Gear, Creeper, Hydrostatic
Forward Gears
6, 9, Infinite (3-range)
Reverse Gears
6, 9, Infinite (3-range)
Total Gears
-

Dimensions

Length (in)
87
Width (in)
40.6
Height (in)
72.1
Operating Weight (lb)
1466

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
12
Front Tire Width (in)
5
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag (Agricultural)
Manufacture - End Year
-
Hitch Type
Type I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
