Iseki TM165

Last Updated: June 2024

Overview

The Iseki TM165 tractor is equipped with a three-cylinder, liquid-cooled diesel engine model E3112, providing 16.5 horsepower and with a displacement of 68.5 cubic inches. The engine operates at a rated RPM of 2500 and is started by an electric starter. Power is managed through a gear transmission with creeper option, offering 9 forward and reverse gears to handle a range of tasks. This tractor features power steering, aiding in the ease of maneuverability, and has a standard Category I hitch. The tractor is supported by a wheelbase of 53 inches, and it stands at a notable ground clearance of 10.2 inches. The tractor's overall dimensions are 87 inches in length, 40.2 inches in width, and 72.2 inches in height, with an operating weight of 1477 pounds. The front tread is 30.9 inches, and the rear tread can be adjusted between 32.3 and 36.6 inches, tailored for a variety of row widths. The Iseki TM165's design and capacities are catered toward essential farm duties, including but not limited to tilling, mowing, and hauling.
Show more...

Key Specifications

Power Output: 16.5

Transmission: Gear with Creeper

Operating Weight: 1477

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Iseki
Model
E3112
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
68.5
Bore (in)
3.08
Stroke (in)
3.07
Rated RPM
2500
Power Output (hp)
16.5

Transmission

Type
Gear with Creeper
Forward Gears
9
Reverse Gears
9
Total Gears
-

Dimensions

Length (in)
87
Width (in)
40.2
Height (in)
72.2
Operating Weight (lb)
1477

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag (Agricultural)
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
