Iseki TL3700

Last Updated: September 2024

Overview

The Iseki TL3700 is a compact and capable tractor designed for various farming tasks. It features an Isuzu 4FB1 engine, which is a 4-cylinder, liquid-cooled diesel engine. This engine has a displacement of 110.9 cubic inches and produces 36 horsepower at 2600 RPM. The tractor's power is well-suited for small to medium-sized farms.

One of the standout features of the TL3700 is its transmission, offering 18 forward gears and 6 reverse gears. This wide range of gears allows farmers to choose the perfect speed for different jobs. The tractor measures 126.4 inches long, 60.2 inches wide, and 84.1 inches tall, making it compact enough to work in tight spaces. It weighs 2976 pounds, providing a good balance between stability and maneuverability. The TL3700 comes with agricultural tires on both front and rear, suitable for various field conditions. It also features an electric starter for easy operation and a JIS1 hitch type for attaching implements.
Show more...

Key Specifications

Power Output: 36 hp (26.8 kW)

Operating Weight: 2976 lb (1350 kg)

Fuel Type: Diesel

Iseki TL3700 vs. Similar Tractors

Power Output

The Power Output for the Iseki TL3700 is Below Average. It is greater than 29% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 6.6K+ tractors in our database)

Operating Weight

The Operating Weight for the Iseki TL3700 is Below Average. It is greater than 22% of similar Utility tractors in our database.

Operating weight distribution of Utility tractors

(across 6.4K+ tractors in our database)

Engine Displacement

The Engine Displacement for the Iseki TL3700 is Below Average. It is greater than 25% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the Iseki TL3700 is Above Average. It is greater than 80% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
Isuzu
Model
4FB1
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Induction Type
Naturally Aspirated
Cylinders
4
Displacement
111 ci (1.8 L)
Bore
3.31 in (84.1 mm)
Stroke
3.23 in (82.0 mm)
Rated RPM
2600
Power Output
36 hp (26.8 kW)

Transmission

Forward Gears
18
Reverse Gears
6
