Iseki TK41

Last Updated: June 2024

Overview

The Iseki TK41 is a versatile and robust tractor powered by an Isuzu E4CG diesel engine with a displacement of 134.1 cubic inches. This engine delivers an output of 40.4 horsepower and is liquid-cooled to ensure optimal performance under various operating conditions. The tractor offers a strong transmission system featuring 16 forward and reverse gears, allowing for a wide range of speeds suited to various tasks. The operating weight varies based on configuration, ranging from 3759 pounds with the Roll-Over Protection Structure (ROPS) to 4134 pounds with a cab. With a wheelbase of 73 inches, a ground clearance of 14 inches, and a tire setup of 8-18 front tires and 13.6-26 rear tires (agricultural standard), the TK41 is designed to provide stability and traction on diverse terrains. The front tread is adjustable from 49.2 inches to a wider setting to accommodate different farm tasks. The TK41 is equipped with Category 3 hitch capabilities at the rear, and various features to accommodate attachments for agricultural use.
Show more...

Key Specifications

Power Output: 40.4

Operating Weight: 3759 (with ROPS), 4134 (with cab)

Fuel Type: Diesel

Image Gallery

Technical Specifications

Engine

Manufacturer
Isuzu
Model
E4CG
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
134.1
Bore (in)
3.425
Stroke (in)
3.64
Rated RPM
2500
Power Output (hp)
40.4

Transmission

Type
-
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
135.4
Width (in)
60
Height (in)
89.8 (with ROPS), 89.4 (with cab)
Operating Weight (lb)
3759 (with ROPS), 4134 (with cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
26
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard tires (ag)
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
ROPS, Cab
Starter Type
Electric Starter
Brake Type
-
Hydraulic System Type
-
