Iseki TJ65

Last Updated: June 2024

Overview

The Iseki TJ65 is a utility tractor characterized by its robust and functional design. As ideal for small scale farming, landscaping and yard work, the TJ65 is outfitted with a reliable Iseki E4DE, four-cylinder, liquid-cooled, diesel engine that delivers 64.1 horsepower at 2600 RPM. It boasts a 180.3 cubic inch engine displacement, with a bore and stroke measuring 3.82 and 3.94 inches respectively. It operates on a 4x4 MFWD 4WD chassis and is controlled through power steering, offering ease of maneuverability. The tractor features an 8-speed power shift transmission with 24 forward and reverse gears, indicating flexibility and efficiency in varying work conditions. Structural dimensions specify a length of 149.4 inches, width of 65.8 inches, and a height of 98 inches, with an operational weight of 5600 lbs. This tractor's tire configuration encompasses Ag front tires, specified at 9.5-22, and Ag rear tires at 12.4-36, denoting a strong grip suitable for utility work.
Show more...

Key Specifications

Category: Utility

Power Output: 64.1

Transmission: 8-speed power shift

Drive Type: MFWD 4WD

Operating Weight: 5600

Fuel Type: Diesel

Iseki TJ65 vs. Similar Tractors

Power Output
Average
Greater than 60% of similar tractors.
Operating Weight
Average
Greater than 46% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iseki
Model
E4DE
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
180.3
Bore (in)
3.82
Stroke (in)
3.94
Rated RPM
2600
Power Output (hp)
64.1

Transmission

Type
8-speed power shift
Forward Gears
24
Reverse Gears
24
Total Gears
-

Dimensions

Length (in)
149.4
Width (in)
65.8
Height (in)
98
Operating Weight (lb)
5600

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
MFWD 4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag (Agricultural)
Manufacture - End Year
-
Hitch Type
JIS1
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
