Iseki TJ55

Last Updated: June 2024

Overview

The Iseki TJ55 is a robust utility tractor known for its 4WD (four-wheel drive) chassis and power steering, which improves maneuverability in various farming operations. It has a powerful diesel engine, an Iseki E4DE, which is a 4-cylinder liquid-cooled engine with a displacement of 180.3 cubic inches, capable of delivering 54.3 horsepower at 2600 RPM. The tractor is outfitted with a versatile 8-speed power shift transmission that offers 24 forward gears. Weighing 5203 pounds, the TJ55 is a heavy-duty machine designed for substantial tasks, and with a wheelbase of 84.7 inches, it offers stability during operation. Dimensions include a length of 149.4 inches, a width of 61 inches, and a height of 95.5 inches. The tractor features ag tires and an electric starter system but additional specification details about the hydraulic system, PTO speeds, manufacturing years, and hitch details are not provided. The TJ55's significant ground clearance and adjustable tread widths for both front and rear wheels, ranging from 47.6 to 60.6 inches at the front and 45.3 to 64.2 inches at the rear, allow for versatile use in a variety of soil conditions and applications.
Show more...

Key Specifications

Category: Utility

Power Output: 54.3

Transmission: 8-speed power shift

Drive Type: 4WD

Operating Weight: 5203

Fuel Type: Diesel

Iseki TJ55 vs. Similar Tractors

Power Output
Average
Greater than 52% of similar tractors.
Operating Weight
Average
Greater than 44% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iseki
Model
E4DE
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally Aspirated
Cylinders
4
Displacement (ci)
180.3
Bore (in)
3.82
Stroke (in)
3.94
Rated RPM
2600
Power Output (hp)
54.3

Transmission

Type
8-speed power shift
Forward Gears
24
Reverse Gears
-
Total Gears
24

Dimensions

Length (in)
149.4
Width (in)
61
Height (in)
95.5
Operating Weight (lb)
5203

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
JIS1
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
