Iseki TG6495

Last Updated: June 2024

Overview

The Iseki TG6495 is equipped with a 47.1 horsepower diesel engine. This tractor has a liquid-cooled, four-cylinder engine with a displacement of 134.1 cubic inches, operating at a rated RPM of 2600. The hydrostatic transmission provides an infinite range of forward and reverse gears for versatility in various applications. The four-wheel drive and power steering aid in maneuverability and handling, especially under challenging conditions. With a wheelbase of 76 inches and ground clearance of 13.6 inches, this tractor offers stability and the ability to navigate over uneven terrain. The tractor is offered in different configurations such as with a Roll Over Protection Structure (ROPS) at a weight of 4101 pounds or with a cab, weighing in at 4453 pounds. This model's dimensions are 136.6 inches in length and 62.6 inches in width, with the height varying depending on the presence of ROPS or a cab. The Iseki TG6495 is designed for a variety of tasks thanks to its power, durability, and functional design.
Show more...

Key Specifications

Power Output: 47.1

Transmission: Hydrostatic

Drive Type: 4WD

Operating Weight: 4101 (ROPS), 4453 (cab)

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Iseki
Model
E4CG
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
134.1
Bore (in)
3.425
Stroke (in)
3.64
Rated RPM
2600
Power Output (hp)
47.1

Transmission

Type
Hydrostatic
Forward Gears
Infinite (6-range)
Reverse Gears
Infinite (6-range)
Total Gears
-

Dimensions

Length (in)
136.6
Width (in)
62.6
Height (in)
104.5 (ROPS), 92.7 (cab)
Operating Weight (lb)
4101 (ROPS), 4453 (cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric Starter
Brake Type
-
Hydraulic System Type
-
