Iseki TG373

Last Updated: June 2024

Overview

The Iseki TG373 is a compact utility tractor designed for a variety of tasks in agricultural and horticultural work. Its 4x4 MFWD 4WD chassis gives this model good traction and versatility across different types of terrain. Powered by an Iseki E4CD diesel engine, the TG373 possesses 36.5 horsepower with a displacement of 134.1 cubic inches, and operates at a rated RPM of 2500. Liquid-cooling ensures the engine maintains an optimal temperature during operation. The tractor is steered through a power steering system, enhancing maneuverability and ease of use. It features a 16-speed transmission with wet disc clutch, accommodating a wide range of operating conditions. With a weight of 3792 pounds for models with ROPS and 4178 pounds with a cab, the TG373 is able to perform various tasks without sacrificing stability. Its dimensions include a length of 139.4 inches, width of 60 inches, and height of 91.3 inches. Details about the hydraulic system, PTO speeds, and brakes are not specified in the provided specifications. The TG373 is equipped with standard agricultural tires, front tire size unspecified, and rear tires measuring 13.6-26. The tractor ran on a wheelbase of 78.4 inches, offering notable ground clearance of 14.2 inches for obstacle negotiation. This tractor could be used for a variety of tasks, likely providing dependable service.
Show more...

Key Specifications

Category: Utility

Power Output: 36.5

Drive Type: 4WD

Operating Weight: ROPS: 3792, Cab: 4178

Fuel Type: Diesel

Iseki TG373 vs. Similar Tractors

Power Output
Average
Greater than 33% of similar tractors.
Operating Weight
Average
Greater than 33% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iseki
Model
E4CD
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally Aspirated
Cylinders
4
Displacement (ci)
134.1
Bore (in)
-
Stroke (in)
-
Rated RPM
2500
Power Output (hp)
36.5

Transmission

Type
-
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
139.4
Width (in)
60
Height (in)
91.3
Operating Weight (lb)
ROPS: 3792, Cab: 4178

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
26
Rear Tire Width (in)
13.6
Front/Rear Rim Diameter (in)
Front: 18, Rear: 26
Tire Type
Standard (ag)
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS/Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
